TOPS Y Series sewing machine motor
Advantage:
1. Outstanding performance
2. High efficiency
3. Energy-saving
4. High starting torque
5. Low noise
6. Little vibration
7. Reliable operation and easy maintenance
Application:
Y series three-phase motors are widely used in places where there doesn't exist combustible, explosive or corrosive gas, and without any special requirements, such as machine tools, pumps, fans, transport machinery, mixer, agriculture machinery and food machines, etc.
Operating Conditions:
1. Ambient temperature: -15 ° C≤ θ ≤ 40° C
2. Altitude: ≤ 1000m
3. Rated voltage: 380V
4. Frequency: 50Hz or 60Hz
5. Duty/Rating: Continuous(S1)
6. Insulation class: Class B/F
7. Protection class: IP55/IP54/IP44
8. Cooling method: IC0141
Note:
If you have any special requirements, please contact us.
|
TECHNICAL DATA |
|
|
|
|
|
|
|
|
|
Model |
Output |
Full load |
Tstart/Tn |
Ist/In |
Tmax/Tn |
|
kW |
HP |
Current |
Speed |
Eff |
Power |
|
(A) |
(r/min) |
(%) |
Factor |
|
380V 50Hz Synchronous Speed 3000 r/min (2 poles) |
|
|
|
|
|
|
Y801-2 |
0.75 |
1 |
1.81 |
2830 |
75 |
0.84 |
2.2 |
6.5 |
2.3 |
|
Y802-2 |
1.1 |
1.5 |
2.52 |
2830 |
77 |
0.86 |
2.2 |
7 |
2.3 |
|
Y90S-2 |
1.5 |
2 |
3.44 |
2840 |
78 |
0.85 |
2.2 |
7 |
2.3 |
|
Y90L-2 |
2.2 |
3 |
4.83 |
2840 |
80.5 |
0.86 |
2.2 |
7 |
2.3 |
|
Y100L-2 |
3 |
4 |
6.39 |
2870 |
87 |
0.87 |
2.2 |
7 |
2.3 |
|
Y112M-2 |
4 |
5.5 |
8.17 |
2890 |
85.5 |
0.87 |
2.2 |
7 |
2.5 |
|
Y132S1-2 |
5.5 |
7.5 |
11.1 |
2900 |
85.5 |
0.88 |
20 |
7 |
2.3 |
|
Y132S2-2 |
7.5 |
10 |
15 |
2900 |
86 |
0.88 |
2 |
7 |
2.3 |
|
Y160M1-2 |
11 |
15 |
21.8 |
2930 |
87.2 |
0.88 |
2 |
7 |
2.3 |
|
Y160M2-2 |
15 |
20 |
29.4 |
2930 |
88.2 |
0.88 |
2 |
7 |
2.3 |
|
Y160L-2 |
18.5 |
25 |
35.5 |
2930 |
89 |
0.89 |
2 |
7 |
2.2 |
|
Y180M-2 |
22 |
30 |
42.2 |
2940 |
89 |
0.89 |
2 |
7 |
2.2 |
|
Y200L1-2 |
30 |
40 |
56.9 |
2950 |
90 |
0.89 |
2 |
7 |
2.2 |
|
Y200L2-2 |
37 |
50 |
69 |
2950 |
90.5 |
0.89 |
2 |
7 |
2.2 |
|
Y225M-2 |
45 |
60 |
83.9 |
2970 |
91.7 |
0.89 |
2 |
7 |
2.2 |
|
Y250M-2 |
55 |
75 |
103 |
2970 |
91.5 |
0.89 |
2 |
7 |
2.2 |
|
Y280S-2 |
75 |
100 |
139 |
2970 |
92 |
0.89 |
2 |
7 |
2.2 |
|
Y280M-2 |
90 |
125 |
166 |
2970 |
92.5 |
0.89 |
2 |
7 |
2.2 |
|
380V 50Hz Synchronous Speed 1500 r/min (4 poles) |
|
|
|
|
|
|
Y801-4 |
0.55 |
0.75 |
1.51 |
1390 |
73 |
0.76 |
2.4 |
6 |
2.3 |
|
Y802-4 |
0.75 |
1 |
2.01 |
1390 |
74.5 |
0.76 |
2.3 |
6 |
2.3 |
|
Y90S-4 |
1.1 |
1.5 |
2.75 |
1400 |
78 |
0.78 |
2.3 |
6.5 |
2.3 |
|
Y90L-4 |
1.5 |
2 |
3.65 |
1400 |
79 |
0.79 |
2.3 |
6.5 |
2.3 |
|
Y100L1-4 |
2.2 |
3 |
5.03 |
1430 |
81 |
0.82 |
2.2 |
7 |
2.3 |
|
Y100L2-4 |
3 |
4 |
6.82 |
1430 |
820.5 |
0.81 |
2.2 |
7 |
2.3 |
|
Y112M-4 |
4 |
5.5 |
0.77 |
1440 |
84.5 |
0.82 |
2.2 |
7 |
2.3 |
|
Y132S-4 |
5.5 |
7.5 |
11.6 |
1440 |
85.5 |
0.84 |
2.2 |
7 |
2.3 |
|
Y132M-4 |
75 |
10 |
15.4 |
1440 |
87 |
0.85 |
2.2 |
7 |
2.3 |
|
Y160M-4 |
11 |
15 |
22.6 |
1460 |
88 |
0.84 |
2.2 |
7 |
2.3 |
|
Y160L-4 |
15 |
20 |
30.3 |
1460 |
88.5 |
0.85 |
2.2 |
7 |
2.3 |
|
Y180M-4 |
18.5 |
25 |
35.9 |
1470 |
91 |
0.86 |
2 |
7 |
2.2 |
|
Y180L-4 |
22 |
30 |
42.5 |
1470 |
91.5 |
0.86 |
2 |
7 |
2.2 |
|
Y200L-4 |
30 |
40 |
56.8 |
1470 |
92.2 |
0.87 |
2 |
7 |
2.2 |
|
Y225S-4 |
37 |
50 |
70.4 |
1480 |
91.8 |
0.87 |
1.9 |
7 |
2.2 |
|
Y225M-4 |
45 |
60 |
84.2 |
1480 |
92.3 |
0.88 |
1.9 |
7 |
2.2 |
|
Y250M-4 |
55 |
75 |
103 |
1480 |
92.6 |
0.88 |
2 |
7 |
2.2 |
|
Y280S-4 |
75 |
100 |
140 |
1480 |
92.7 |
0.88 |
1.9 |
7 |
2.2 |
|
Y280M-4 |
90 |
125 |
164 |
1480 |
93.5 |
0.89 |
1.9 |
7 |
2.2 |
|
380V 50Hz Synchronous Speed 1000 r/min (6 poles) |
|
|
|
|
|
|
Y90S-6 |
0.75 |
1 |
2.25 |
910 |
72.5 |
0.7 |
2 |
5.5 |
2.2 |
|
Y90L-6 |
1.1 |
1.5 |
3.16 |
910 |
73.5 |
0.72 |
2 |
5.5 |
2.2 |
|
Y100L-6 |
1.5 |
2 |
3.97 |
940 |
77.5 |
0.74 |
2 |
6 |
2.2 |
|
Y112M-6 |
2.2 |
3 |
5.61 |
940 |
80.5 |
0.74 |
2 |
6 |
2.2 |
|
Y132S-6 |
3 |
4 |
7.23 |
960 |
83 |
0.76 |
2 |
6.5 |
2.2 |
|
Y132M1-6 |
4 |
5.5 |
9.4 |
960 |
84 |
0.77 |
2 |
6.5 |
2.2 |
|
Y132M2-6 |
5.5 |
7.5 |
12.6 |
960 |
5.3 |
0.78 |
2 |
6.5 |
2 |
|
Y160M-6 |
7.5 |
10 |
17 |
970 |
86 |
0.78 |
2 |
6.5 |
2 |
|
Y160L-6 |
11 |
15 |
24.6 |
970 |
87 |
0.78 |
2 |
6.5 |
2 |
|
Y180L-6 |
15 |
20 |
31.4 |
970 |
89.5 |
0.81 |
1.8 |
6.5 |
2 |
|
Y200L1-6 |
18.5 |
25 |
37.7 |
970 |
89.8 |
0.83 |
1.8 |
6.5 |
2 |
|
Y200L2-6 |
22 |
30 |
44.6 |
970 |
90.2 |
0.83 |
1.8 |
6.5 |
2 |
|
Y225M-6 |
30 |
40 |
59.5 |
980 |
90.2 |
0.85 |
1.7 |
6.5 |
2 |
|
Y250M-6 |
37 |
50 |
72 |
980 |
90.8 |
0.86 |
1.8 |
6.5 |
2 |
|
Y280S-6 |
45 |
60 |
85.4 |
980 |
92 |
0.87 |
1.8 |
6.5 |
2 |
|
Y280M-6 |
55 |
75 |
104 |
980 |
92 |
0.87 |
1.8 |
6.5 |
2 |
|
380V 50Hz Synchronous Speed 750 r/min (8 poles) |
|
Y132S-8 |
2.2 |
3 |
5.85 |
710 |
80.5 |
0.71 |
2 |
5.5 |
2 |
|
Y123M-8 |
3 |
4 |
7.72 |
710 |
82 |
0.72 |
2 |
5.5 |
2 |
|
Y160M1-8 |
4 |
5.5 |
9.91 |
720 |
84 |
0.73 |
2 |
6 |
2 |
|
Y160M2-8 |
5.5 |
7.5 |
13.3 |
720 |
85 |
0.74 |
2 |
6 |
2 |
|
Y160L-8 |
7.5 |
10 |
17.7 |
720 |
86 |
0.75 |
2 |
5.5 |
2 |
|
Y180L-8 |
11 |
15 |
24.8 |
730 |
87.5 |
0.77 |
1.7 |
6 |
2 |
|
Y200L-8 |
15 |
20 |
34.1 |
730 |
88 |
0.76 |
1.8 |
6 |
2 |
|
Y225S-8 |
18.5 |
25 |
41.3 |
730 |
89.5 |
0.76 |
1.7 |
6 |
2 |
|
Y225M-8 |
22 |
30 |
47.6 |
730 |
90 |
0.78 |
1.8 |
6 |
2 |
|
Y250M-8 |
30 |
40 |
63 |
740 |
90.5 |
0.8 |
1.8 |
6 |
2 |
|
Y280S-8 |
37 |
50 |
78.2 |
740 |
91 |
0.79 |
1.8 |
6 |
2 |
|
Y280M-8 |
45 |
60 |
93.2 |
740 |
91.7 |
0.8 |
1.8 |
6 |
2 |
