Features and benefits:
Best choice for home-hold electric devices in towns or villages
Easy transport with handle and wheels
Easy use and maintenance
Low fuel consumption, low noise and low pollution
Recoil starter
|
Model |
DAG2500X |
DAG3500X |
DAG5500X |
DAG6500X/E |
|
Rated frequency (Hz) |
50 |
50 |
50 |
50 |
60 |
|
Rated output(kVA) |
2 |
2.8 |
5 |
6 |
7 |
|
Max. ouput (kVA) |
2.2 |
3.1 |
5.5 |
6.5 |
8 |
|
Rated voltage (V) |
220 |
220 |
220 |
220 |
240 |
|
Engine Model |
168F-2 |
173F |
188F |
190FD |
|
Engine type |
4-stroke, forced-cooled, single-cylinder, OHV |
4-stroke, forced-cooled, single-cylinder, OHV |
|
Displacement |
196ml |
242ml |
389ml |
420ml |
|
Rated power[kW(Hp)/(r/min)] |
4.0/3600 |
5.1/3600 |
8.2/3600 |
8.5/3600 |
|
Max. power[kW(Hp)/(r/min)] |
4.8/3600 |
5.8/3600 |
9.5/3600 |
9.5/3600 |
10.5/3600 |
|
lgnition system |
Non-contact transistorized magneto |
|
Starting system |
Manual |
Manual |
Manual |
Manual/Electric |
|
Fuel tank capacity (L) |
15 |
25 |
25 |
25 |
|
Fuel consumption (L/hr) |
1.13 |
1.9 |
2.7 |
4 |
|
Continuous operating time (hr) |
13 |
13 |
9 |
6 |
|
Oil capacity (L) |
0.6 |
1.1 |
1.1 |
1.1 |
|
Noise Level(7M) db(A) |
65 |
69 |
74 |
74 |
|
Overall dimension: L× W× H(mm) |
590*430*485 |
680*510*540 |
680*510*540 |
680*510*540 |
|
Dry weight (Kg) |
45 |
65 |
80 |
90 |
|
Carton dimension: L× W× H(mm) |
645*490*490 |
730*575*595 |
730*575*595 |
730*575*595 |
"Innovation,Quality,Humanization",that's what DOUBLE-ARROW always believes in since it was founded in 1999.Providing customers with reliable and high -quality products and with the joint effort of professionals and advanced management is what we are persuing all the time.
DOUBLE-ARROW is located in Wuxi, which is the flourishing area of the world manufacturing, an hour from Shanghai. DOUBLE-ARROW devotes itself to designing,manufacturing and installing a variety of products,such as power generator set,engine,water pump and related products.
Specialized in power generator sets, we supply a complete line of generators for commercial and consumer applications, including diesel portable generators,gasoline portable generators,residential standby generators, and industrial generators. DOUBLE-ARROW generators covers a wide power range from 0.5KVA to 3000KVA with varied type including open frame type,soundproof type,mobile type and containerized type etc.With more than 10 years experience of engaging in this business line, we are able to provide the customers excellent products with high quality,competitive price,good service.
We pay much attention to the quality of products, and has been certified by ISO9001 and ISO 14000 systems.Each step of manufacturing is strictly carried out in accordance with these standard. Nowadays,most of our products are certificated with CE,EPA etc.
After more than 10 years development with our culture "Innovation,Quality,Humanization", DOUBLE-ARROW products had been sold to more than 100 countries and regions,a world-wide sales and service net is taking shape gradually.
We warmly welcome your joining with us and hope that will bring mutual benefit to both parties in near future.
