System introduction:
Photovoltaic pump system is widely used in the water for living, agricultural irrigation, forestry irrigate, desert grassland livestock, island management, water supply, water treatment engineering. In recent years, along with the continuous increase of new energy use, in municipal engineering, the city square, park and sightseeing, tourism resorts, hotels and residential community landscape and water spray system, PV pump systems have been more and more applications. The system is compsed of the photovoltaic array, inverter and water pump, and omit the energy storage devices such as battery.
Characteristics:
1) Independent research of the true Maximum Power Point Tracking technology (TMPPT), effectively improve the utilization rate of the photovoltaic panels;
2) Using the fifth generation efficient power supply module IPM produced by Mitsubishi Company, high reliability;
3) The digital control, have fully automatic operation, data storage and complete protection function;
4) LCD display function, can view and set up various operation parameters.
|
model |
pump motor |
Maximum Photovoltaic Power Input
(KWP) |
The Max DC Input Voltage(V) |
Recommend MPPT Voltage (V) |
Rated AC Output Current (A) |
Output Frequency
(HZ) |
|
Rated Power (KW) |
Rated Voltage (V) |
|
LFP400L |
0.25~0.4 |
200~220 |
0.6 |
430 |
280~350 |
3 |
0~60 |
|
LFP750L |
0.55~0.75 |
200~220 |
1.1 |
430 |
280~350 |
5 |
0~60 |
|
LFP1500L |
1.1~1.5 |
200~220 |
2.2 |
430 |
280~350 |
7 |
0~60 |
|
LFP2200L |
2.2 |
200~220 |
3.3 |
430 |
280~350 |
11 |
0~60 |
|
LFP3700L |
3~3.7 |
200~220 |
5 |
430 |
280~350 |
17 |
0~60 |
|
LFP3700H |
3~3.7 |
380~440 |
5 |
750 |
500~600 |
9 |
0~60 |
|
LFP5500H |
4~4.5 |
380~440 |
8 |
750 |
500~600 |
13 |
0~60 |
|
LFP7500H |
7.5 |
380~440 |
10 |
750 |
500~600 |
18 |
0~60 |
|
LFP11KH |
9.2~11 |
380~440 |
15 |
750 |
500~600 |
24 |
0~60 |
|
LFP15KH |
13~15 |
380~440 |
21 |
750 |
500~600 |
30 |
0~60 |
|
LFP18KH |
18.5 |
380~440 |
25 |
750 |
500~600 |
39 |
0~60 |
|
LFP22KH |
22 |
380~440 |
30 |
750 |
500~600 |
45 |
0~60 |
|
LFP30KH |
26~30 |
380~440 |
42 |
750 |
500~600 |
60 |
0~60 |
|
LFP37KH |
37 |
380~440 |
50 |
750 |
500~600 |
75 |
0~60 |
|
LFP45KH |
40~45 |
380~440 |
60 |
750 |
500~600 |
91 |
0~60 |
|
LFP55KH |
55 |
380~440 |
75 |
750 |
500~600 |
112 |
0~60 |
