1. Fan-driven generator
2. Sine wave
3. Noisy emission level < 60dB,
4. Maglev technology
5. CE&RoHS
Product Description:
Adopt high-quality and high-strength permanent materials to ensure high energy conversion efficiency.
Adopt high-quality and high-strength aluminum alloy to make the unit light weight and easy installation.
The fiber-glass blades have the advantages of great intensity and excellent fatigue resistance.
Stainless steel shaft and screws to avoid rust and corrosion.
And the surface is coated with pollution-free material. Working environmental temperature from -20C-50C.
Electromagnetic brake is with the function of over-speed and over-current protection
|
power |
300W |
500W |
1KW |
2KW |
3KW |
5KW |
10KW |
20KW |
|
the diameter of wind wheel |
1.8m |
1.8m |
2m |
2. m |
3.2m |
3.2m |
3.2m |
3.2m |
|
blades number |
3 |
3 |
4 |
4 |
5 |
5 |
7 |
9 |
|
blades length |
1m |
1m |
1m |
1m |
1.6m |
1.6m |
1.6m |
1.6m |
|
rated rotate speed |
150(r/min) |
150(r/min) |
150(r/min) |
150(r/min) |
160(r/min) |
160(r/min) |
160(r/min) |
150(r/min) |
|
rated wind speed |
7-8m/s |
7-8m/s |
7-8m/s |
7-8m/s |
7-8m/s |
7-8 m/s |
10-11m/s |
12m/s |
|
start up wind speed |
2m/s |
2m/s |
2.5m/s |
2m/s |
3m/s |
3m/s |
3m/s |
3m/s |
|
working wind speed |
3-24(m/s) |
3-24(m/s) |
3-24(m/s) |
3-24(m/s) |
3-24(m/s) |
3-24(m/s) |
3-24(m/s) |
3-24m/s |
|
security wind speed |
40m/s |
40m/s |
40m/s |
40(m/s) |
40(m/s) |
50(m/s) |
50(m/s) |
50(m/s) |
|
rated power |
300W |
500W |
1KW |
2KW |
3KW |
5KW |
11KW |
21KW |
|
the max power |
350W |
550W |
1.5KW |
2.5KW |
4.5KW |
6.5KW |
11KW |
21KW |
|
output voltage(DC) |
220V |
220V |
220V |
220V |
220V |
220V |
220/110V |
380V |
|
the height of tower |
8m |
10m |
10m |
10m |
10m |
10m |
10m |
14m |
|
the top part weight |
49kg |
63KD |
73kg |
78kg |
98kg |
102kg |
|
|
|
battery reference |
12V100ah, 2pc |
12V100ah, 2pcs |
12V100ah, 4pcs |
12v150ah 4pcs |
