We can supply Perkins Diesel Genset / diesel generator / power generator(10kVA-2500kVA)
Perkins diesel generator set is one of best sale products. Newline as the OEM for Perkins generator company is moving forward best power supplier around the world.
Product Specifications: NPP Series 166KW-200KW
Parameter of 1106 Series Genset
Standby 183KW, 200KW, 220KW
British Perkins Engine Corporation is a world-renowned engine manufacturing company. Founded in 1932, it In the Nineties of last century took over another well-known international brand of Rolls-Royce, developing to the present annual output of 300, 000 engines, and rapidly occupied the global market by the full engine series, good structure, reliable performance, easy maintenance, and low fuel consumption. The company has three production bases worldwide and more than 4, 000 after-sales service network around the world, and has produced more than 15 million engines.
ModelNPP166, NPP182, NPP200 | Standby | Prime | Standby | Prime | Standby | Prime |
Rated Power | KW/KVA | 183/229 | 166/208 | 200/250 | 180/225 | 220/275 | 200/250 |
Rated Current | A | 348 | 315 | 380 | 342 | 418 | 360 |
Rated Voltage | V AC | 220/380 |
Rated Frequency | HZ | 50 | 50 | 50 |
Power Factor(lagging) | | 0.8 | 0.8 | 0.8 |
Output | | 3-Phase, 4-Line |
Dimension(L*W*H) | mm | 2950 × 1300 × 1920 |
Weight | Kg | 2200 | 2200 | 2250 |
Origin | | China | China | China |
Engine | | PERKINS | PERKINS | PERKINS |
Model | | 1306C-E87TAG3 | 1306C-E87TAG4 | 1306C-E87TAG8 |
Output Power | KW | 205 | 186 | 224 | 204 | 246 | 224 |
Rev | RPM | 1500 | 1500 | 1500 |
Style | | 4-Stroke, L-6 Cylinder, Turbocharging, Water-cooled |
Compression | | 16.9: 1 |
Bore*Stroke | | 116.6mm × 135.9mm |
Cylinder Capacity | | 8.7L | 8.7L | 8.7L |
Fuel Systerm | | Diesel, Perpendicular incidence |
Governor | | Electronical | Electronical | Electronical |
Noise Average Level(1m) | dBA | 95 | 95 | 95 |
100% Full-load Fuel Consumption | L/H | 49.1 | 53 | 59.9 |
Lube oil model, Capacity | | CD LEVEL AND UP 15W/40 28.3L |
Coolant working temperature, Capacity | | 79-103Celsius Degree 38L |
Start-up Battery | | 24VDC or 12VDC |
Exhaust Exit Dimension | mm | 125 | 125 | 125 |
Max Exhaust Backing Pressure | kpa | 10.7 | 10.7 | 10.7 |
Max Exhaust Temperature | Celsius Degree | 524 | 526 | 528 |
Max Exhaust Flow | m ³ /min | 36.5 | 40.3 | 44.5 |
Cooling Fan Flow | m³ /min | 375 | 375 | 375 |
Alternator | | Stamford, Leroy-somer, ... |
Alternator Style | | Single-bearing, Rotating field, 4-Pole |
Excitation method | | Brush less, Self-excitation |
Insulaton Grade | | H |
Defend Grade | | IP22 |
Voltage Regulation Form | | Automatic |
Control Part | | MANUAL |
More than 20 years since its establishment, China Machine Energy Technology Co., Limited insists on the business mode of solution design, turnkey project sell and whole-process service.According to the various powers demands and requests, we provide the turnkey power supply solution and one-stop service for our customers personalized requests.
Under the new energy era, we insists on the direction of promoting green and environmental generator sets and associated engineering solution as our preferred strategic products.
For the special lack of electricity area and electricity consumption cost higher enterprises, we provide independent power station design scheme, leasing and contracting business.
Combined with globe update green and conservative new energy technologies and products, we cordial to service our clients with the on time, advanced and economic power solution of firming to reduce energy costs and responding low-carbon economy trend.
Our main business series are diesel generator sets, new energy generator sets, independent power station projects and green & energy conservative projects.
China Machine Energy Technology Co., Limited is willing to cooperate with you and create a better life!
