PRODUCT PARAMETER
| Item No. | DT-SOGS-400-02 |
| Solar Panel power | 18V/400Wp(Polycrystalline silicon) |
| Battery capacity | 12V/200AH |
| Charge controller | 12V/20A |
| DC Output voltage | ((12V/8A)4,(USB 5V/800MA)2 |
| AC output voltage |
Pure 1000W |
| Shell Material | 1.0mm Cold Drawing |
| Power indicator light | yes |
| AC Charge | yes |
| Unit Size | 55CM*45CM*52CM |
Accessories | main engine 1set,solar panel 4pcs,Lamp holder line 2pcs,3W lamp bulb 2pcs,phone line 1pc |
Products Features
1.solar generator do not need fuel such as oil,gas,coal etc,it absorb sunlight and turn to power directly,free
of charge,improve the life quality of non-electricity area.
2.Use high efficient solar panel,tempered glass frame,fashionable and beautiful,solid and practical,easy to carry and transport.
3.Solar generator built-in charging and power display function,will let you know charge and discharge status ensure enough power for using.
4. Simple input and output equipment,do not need install and debugging integrated design make operation convenient and fast.
5.Built-in DC 12V and USB 5V output,can be used to small household appliances.
6.Built-in free of maintain battery,protect from overcharge,over discharge,overload and short circuit.
7.Solar home light generator,silent,lightweight exquisite,shockproof and dustproof,green energy,environmental
health,widely used in farm,ranch,posts,fish farming,and other border areas without electricity.
Switch & interface using instruction
1.DC switch:when lack of power,turn on the switch,battery voltmeter will show voltage,at the same time,DC output interface will have DC voltage output,when you do not need DC output,you can turn off.Noted:this switch is DC output,include USB output.
2.USB interface:output 5V/500mA,used to USB interface appliance,turn off DC switch when using.
3.Charging display:user can know if the receive function is normal.when the light flash,that means it is full of charge,Noted :the light will not shine in rainy weather.
4.Battery voltmeter:you can know the battery electricity by observation.
Installation & Precautions
1. Installation of system:connect the solar panel cable to corresponding terminal,the put the solar panel in the position with sunshine,put the host indoor,the first use of the need to install the fuse.
2. Charging use:put the solar panel in the position with sunshine,connect the plug into correct"+"and "-" position,the light will shine at that time,that means it is in charging process.When sunshine enough,the charging indicator will shine.(Noted:Under any running state,ensure the charging equipment connected well,it is not related to on/off status,can charge at any time,the system built-in charging protection.It is better to connect solar panel in long term if possible,do not need to break.)
Malfunction diagnosis and troubleshooting
1. Solar panel indicator do not shine ?
Check the solar panel is connected well,do not open circuit or reverse connection.
(Noted:when charge by normal sunshine,the indicator will shine,ensure solar panel works well)
2. Solar charge is low efficient?
Check the solar panel if ther is sundries cover the sunshine or the connect cable aging,the solar panel should clean termly.
3. The output indicator do not shine ?
Check the power if it is enough,it is lack of power if the voltmeter showed under 11V,please charge it soon if lack of power.Overload or short circuit will also make it without output,you should pull out load and decrease the load,Restart will recover output antomatically.
Quality Control:
Our production management strictly according to ISO9001 standard and we have CE certification. From material purchasing to packing, we test in every steps in order to make sure our products are qualified.
