Generator Manufacturers and Factories

Home Generator Products Ozone Generator for Water Treatment and Portable Air Purifier S3500

Ozone Generator for Water Treatment and Portable Air Purifier S3500

Ozone Generator for Water Treatment and Portable Air Purifier S3500
Price: US $ 170/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 500/Piece
Pay Type: L/C,T/T,Paypal,Western Union
Ozone Generator (S3500)

ModelYL-S3500Input PowerAC220V
Voltage3.0~3.5KVWorking Frequency50Hz
Power60WOzone Output7g/h
Ozone Concentration16-20mg/LEffective Area0-150m3
MaterialStainless Steel Dimensions380x156x200mm

l Ozone generator is a compact machine which can sterilize the air by its oxidation and be deoxidized into oxygen without secondary pollution.
l Outer electrical pole is made of stainless steel and takes anti-puncture crystal as a dielectric. The discharge compartment is wholly sealed to keep the unit operation safely.
l PSU (Power Supply Unit) is the core technique of the unit, included frequency conversion and boost converter. It adopts soft start to make the unit to operate stably with high load capacity and highly efficient.
l The equipment should operate together with a clean air intake.
Discharge compartment is cooled by wind cooling system. The equipment will produce electric

l discharge sound and ozone output stably without damaging components.

l The equipment should operate in dry and ventilated spaces. Please shield it from direct sunshine and rain, if it must work outside.
l For air purification, the equipment can operate with a silicon hose and the other end of the hose leads to the place where need to sterilize. For water purification, the equipment can operate with a silicon hose and the other end of the hose is put into water with an air stone.
l Please make sure the silicon hose is in good condition and proper function.
l Please verify the whether one-way valve and the silicon hose is in the right direction or not.
l Insert into 220V socket with a earth wire and voltage meter.
l Switch on the equipment on, it operates continuously.
l Switch the off, set the right timing and your desired operation time from 1min to 60 mins.
l Turn the switch and operation indicator on (green light), pump operates. Twisting the knob and set the time for ozone output.
l Do not smell ozone with your nose directly from the ozone outlet.
Failure Analysis

NO.General FailureFailure AnalysisSolution
1Power indicator off1.No power
2.Fuse damaged
3. Indicator damaged1. Connect the power
2. Replace the fuse
3. Replace the indicator
2Operation indicator off1. No power
2. Fuse damaged
3. Indicator damaged1. Connect the power
2. Replace the fuse
3. Replace the indicator
3No ozone output1.Discharge bad bulb
2. Silicon hose damaged
3. Pump damaged1. Replace the discharge bulb or control circuit board
2. Replace the silicon hose
3. Replace the pump
4Small amount of ozone1. Discharge aged bulb
2. Ozone bulb hot1. Replace the discharge bulb
2. Replace the fan

Care and Maintenance
l Please keep the surface of unit clean.
l Please replace the silicon hose when it is broken.
l When used for air purification, it is advised that people should leave the sterilization area in case of respiratory system stimulation because of high density of ozone.
When used as water purification, please mount with anti-reflux device in case of damaging the unit

l (It is advised to put antioxidant in the air intake to keep ozone dry).
l The voltage is 220V/50Hz and there is high voltage inside. Please make sure there is a earth wire and avoid electric shock.
l Do not smell ozone directly in case of respiratory system stimulation. Especially the pregnant and children.
l Please shut off the power if it do not use for a long time.

Neutral Box
Carton Dimensions: 46x22x26cm
Qty per Carton: 1pc
G.W./N.W. of Carton: 5.8/4.75kg
Prod Model: S3500
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 44*38*39
Ozone Output: 3.5g/H
Waltage: 40W
Effectiv Area: 150m3
Type: Ozone
Usage: Home
Purifying Technology: Ozone
Air Volume: 301-400m³/h
Power Source: AC Source
Certification: CE
Operating Principle: Active
Structure: Portable
Application Area: >61m²
