Characteristics:
(1) Convenient all in one system: Generating, sourcing and cooling system;
(2) PSA (Pressure Swing Absorption) system feeding high oxygen;
(3) Dry air system which feeding high quality dry oxygen;
(4) Patent ceramic ozone generators with high quality material and long life;
(5) High ozone concentration and oxygen saving;
(6) IGBT Power to generate strong electric field and corona discharge;
(7) Generating units of module style keep them easy maintenance separately;
(8) Both electrodes cooling system keeps ozone output with high stably;
(9) Advanced automatic time control to run without labor watch.
Feeding Source Classes: (The material gas to generate the ozone is the oxygen which usually includes the clean air, pure oxygen and ambient air, so the oxygen concentration, flow capability, dew point and impurity percent will affect the ozone output clearly and certainly the proper air source will run the machine with stable ozone output and long life. Below the four styles. )
(1) A style (rich oxygen): Places of high ozone concentration such as purified water, mineral water and disinfecting water;
(2) B style (dry air): Places of low ozone concentration and high flow such as space disinfection, machine and food rooms, tap water, swimming pool, aquatic water, production recycling water, supercritical water and polluted water;
(3) P style (industrial oxygen): Places of high ozone purity and concentration but low flow such as laboratories;
(4) C style (ambient air): Places with clean and dry air
Applicable Areas:
(1) Drinking Water, Waste Water, Swimming Pool, Aquatics Water, Foods Workshop, Foods Process Equipment;
(2) Production Water, Spicery Catalyze, Paper Pulp Bleach, Biologic and Chemical Pollution, Plastic Membrane.
Technical Parameters 1 (Basic Specs)
Input Voltage
Frequency
Dew Point
Input Temperature
Ozone Concentration
Cooling Water Temperature
Output Pressure
Oxygen
Ambient Air
380V/3PH/50HZ
12-15KHZ
-45'C
20'C
50-80mg/L
12-16mg/L
20'C(10%)
0.05-0.1MPa
Technical Parameters 2 (Air Source)
Model No.
Ozone Output (g/h)
Ozone Flow (m3/hkgo3)
Water Flow (m3/h)
Power (Kw/kgo3)
Dimensions (mm)(LxWxH)
SY-G300G
300
60-80
1.2
18-20
1580x880x1720
SY-G400G
400
1.6
1580x880x1720
SY-G500G
500
2.0
1580x880x1720
Technical Parameters 3 (Oxygen Source)
Model No.
Ozone Output (g/h)
Ozone Flow (m3/hkgo3)
Water Flow (m3/h)
Power (Kw/kgo3)
Dimensions (mm)(LxWxH)
SY-G300G
300
12-15
1.2
8-10
1580x880x1720
SY-G400G
400
1.6
1580x880x1720
SY-G500G
500
2
2110x880x1720
SY-G600G
600
2.4
2110x880x1720
SY-G800G
800
2.8
2110x880x1720
SY-G1000G
1000
4
2110x880x1720
SY-G1500G
1500
6
2110x880x1720
With the life improving people are taking more and more attention on the environment and health. Like the food we eat, the water we drink and the air we breathe has a great impact on our health. Obviously, we have a concern that our survival depends on the availability of clean air and water, and the OCIC series air/water purifiers will just satisfy you by reducing many pollutants, bacterias and virus etc.
