Original Deutz Silent Diesel Engine Generator with CE Approval (60kVA~650kVA)
Price: |
US $ 5000/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
60kVA~650kVA Original Deutz Silent Diesel Engine Generator with CE/Soncap/CIQ Approval60kVA~650kVA Deutz Silent Diesel Engine Generator are equipped with advanced technology engine. The 60KVA~275KVA V*DG series genset is equipped with original Deutz brand engine made by Germany Deutz in China Dalian factory. And 225KVA~625KVA are equipped with Deutz brand engine made by Huachai factory. Victory-Deutz Diesel Gen-set is a set of complete equipment for electrical power supply. Adopting modular design, the engine features compact structure, large power output, economy, reliability, high universality of the spare parts and easy maintenance. Deutz engines, high-quality generators and advanced full-automatic control system are produced through strict test, which together provides reliable power no matter as standby, prime or continuous use. The capacity is is from 60KVA to 625KVA. It is departed into normal generating sets and automatic generating sets according to its control panel. It can be matched into trailer type, soundproof type etc. The manufacturing and inspection of generating sets fit to GB/T2820-1997 Standard.
General specifications of silent engine generator:
1. Modular design
2. Anti-corrosion powder coated
3. Insulated with acoustic foam lining
4. Central lifting ring, exhaust pipe can be removed which is easy for ransportation
5. Lockable doors with key, and doors fitted on each side
6. Protective mesh for rotating parts
7. Exterior emergency stop push button
8. Thermally insulated engine exhaust system
9. Panel observing window
10. Access to radiator filling or cap
11. 20', 30' or 40' container canopy is optional
Fuel gauge or lube drain valve is optional
Normal or super soundproof canopy is optional
Base frame fuel tank or profile fuel tank is optional
The muffler's fixed position depend on the output power of gen-set
Silent generator set canopy:
* With special treated steel sheet
* StaiVess steel locks
* Control panel viewing window for monitoring the status of the generator set
* Good ventilation system and anti-heat radiation struction
* Effective anti-vibration devices to ensure the geneartor set run steadily
* Super silent materials inside to ensure the noise lower than 68 dB 7 meters away
* Emergency stop button mounted outside
* Side lockable door easy for maintenance and installation
* Lube oil and cooling water drains piped to exterior of the canopy
* Fuel tank built-in with level gauge
Paramters:
1. Rated voltage: 400V/230V, 380V/220V, 240V/120V, 220V/110V
2. Line way: 3 phases & 4 lines
3. Frequency: 50Hz/60Hz
4. Power factor: 0.8 (lagging)
5. Frequency down (%): ≤ 0.5
6. Steady voltage windage (%): ≤ ± 1
7. Instantanous frequency windage (%): (rated power ) +10~ -7
8. Frequency recovering time (s): ≤ 3
9. Instantanous voltage windage (%): +20~ -15
10. Voltage recovering time (S): ≤ 4
11. Wave form distortion (%): ≤ 5Engine Generator Features:
1. Heavy load, durable 4-stroke water-cooled engine;
2. Small size, light weight, compact structure, efficient output, reliable performance and economy;
3. Electronic or mechnical governor;
4. Fuel system: A type multi-cylinder combined injection pump and closed multi-hole injector have been used in combustion system; two-pole fuel filter ensures the cleaning fuel in injection pump, and increases the lifetime of injection pump.
5. P type small pressure chamber Eurasian extrusive and grinding injector has been used to improve the quality of atomization.
6. Structure:
Cylinder Heads: High strength nodular iron casting;
Connecting Rods: Drop Forged High Carbon Alloy Steel;
Crankshaft: High Steel Forging, bolt-on counterweights;
Cylinder liners: Replaceable humid cylinder liner;
7. Intake System: Dry element air filter with visual restriction indicators, turbocharged (intercooler).
Genset model | Freq uency (HZ) | Prime Power | Standby Power | Engine model | Fuel consumption under full load (L/H) | Cyli nder | Volt. For start (DC) | Size L X W X H (mm) | Weight (kg) |
KW | KVA | KW | KVA |
V53DG | 50 | 48 | 60 | 53 | 66 | BF4M2012 | 16.9 | 4L | 24V | 1870 x 980 x 1500 | 970 |
V62DG | 60 | 56 | 70 | 62 | 78 | 18.9 |
V65DG | 50 | 58 | 73 | 65 | 81 | BF4M2012C | 19.3 | 4L | 24V | 1960 x 980 x 1500 | 1040 |
V77DG | 60 | 70 | 88 | 77 | 96 | 22.7 |
V75DG | 50 | 68 | 85 | 75 | 93 | BF4M1013E | 25.8 | 4L | 24V | 2140 x 980 x 1700 | 1180 |
V84DG | 60 | 76 | 95 | 84 | 105 | 28 |
V88DG | 50 | 80 | 100 | 88 | 110 | BF4M1013EC | 25.8 | 4L | 24V | 2090 x 980 x 1700 | 1220 |
V100DG | 60 | 90 | 113 | 100 | 125 | 28 |
V112DG | 50 | 100 | 125 | 112 | 140 | BF4M1013FC | 32.3 | 4L | 24V | 2280 x 980 x 1700 | 1310 |
V120DG | 60 | 110 | 138 | 120 | 150 | 36.5 |
V132DG | 50 | 120 | 150 | 132 | 165 | BF6M1013EC | 38.5 | 6L | 24V | 2500 x 980 x 1700 | 1590 |
V154DG | 60 | 140 | 175 | 154 | 193 | 41.8 |
V160DG | 50 | 146 | 182 | 160 | 200 | BF6M1013FCG2 | 45.9 | 6L | 24V | 2640 x 1150 x 1790 | 1710 |
V200DG | 60 | 180 | 225 | 200 | 250 | 52.7 |
V180DG | 50 | 160 | 200 | 180 | 225 | BF6M1013FCG3 | 50.8 | 6L | 24V | 2640 x 1150 x 1790 | 1760 |
V220DG | 60 | 200 | 250 | 220 | 275 | 60.2 |
V200DH | 50 | 180 | 225 | 200 | 250 | BF6M1015-LAGA | 53 | 6V | 24V | 2500 x 1250 x 2150 | 2193 |
V220DH | 60 | 200 | 250 | 220 | 275 | BF6M1015-LAGB | 58 | 6V | 24V | 2500 x 1250 x 2150 | 2193 |
V220DH | 50 | 200 | 250 | 220 | 275 | BF6M1015C-LAG1A | 58 | 6V | 24V | 2630 x 1410 x 2150 | 2228 |
V240DH | 60 | 220 | 275 | 240 | 300 | BF6M1015C-LAG1B | 64 | 6V | 24V | 2630 x 1410 x 2150 | 2228 |
V250DH | 50 | 230 | 288 | 250 | 313 | BF6M1015C-LAG2A | 66 | 6V | 24V | 2730 x 1410 x 2150 | 2423 |
V264DH | 60 | 240 | 300 | 264 | 330 | BF6M1015C-LAG2B | 70 | 6V | 24V | 2730 x 1410 x 2150 | 2423 |
V280DH | 50 | 250 | 313 | 280 | 350 | BF6M1015C-LAG3A | 73 | 6V | 24V | 2730 x 1410 x 2150 | 2503 |
V300DH | 60 | 270 | 338 | 300 | 375 | BF6M1015C-LAG3B | 79 | 6V | 24V | 2730 x 1410 x 2150 | 2503 |
V310DH | 50 | 280 | 350 | 310 | 388 | BF6M1015C-LAG4 | 82 | 6V | 24V | 2830 x 1410 x 2150 | 2641 |
V330DH | 50 | 300 | 375 | 330 | 413 | BF6M1015CP-LAG | 89 | 6V | 24V | 2830 x 1410 x 2230 | 2679 |
V380DH | 50 | 350 | 438 | 380 | 475 | BF8M1015C-LAG1A | 102 | 8V | 24V | 3100 x 1560 x 2150 | 3263 |
V400DH | 60 | 360 | 450 | 400 | 500 | BF8M1015C-LAG1B | 106 | 8V | 24V | 3100 x 1560 x 2150 | 3263 |
V400DH | 50 | 360 | 450 | 400 | 500 | BF8M1015C-LAG2 | 106 | 8V | 24V | 3100 x 1560 x 2150 | 3263 |
V420DH | 50 | 380 | 475 | 420 | 525 | BF8M1015CP-LAG1A | 113 | 8V | 24V | 3100 x 1560 x 2150 | 3263 |
V420DH | 60 | 380 | 475 | 420 | 525 | BF8M1015CP-LAG1B | 112 | 8V | 24V | 3100 x 1560 x 2150 | 3263 |
V440DH | 50 | 400 | 500 | 440 | 550 | BF8M1015CP-LAG2 | 118 | 8V | 24V | 3100 x 1560 x 2150 | 3263 |
V450DH | 50 | 410 | 513 | 450 | 563 | BF8M1015CP-LAG3 | 121 | 8V | 24V | 3100 x 1560 x 2150 | 3363 |
V470DH | 50 | 430 | 538 | 470 | 588 | BF8M1015CP-LAG4 | 127 | 8V | 24V | 3100 x 1560 x 2150 | 3363 |
V500DH | 50 | 450 | 563 | 500 | 625 | BF8M1015CP-LAG5 | 133 | 8V | 24V | 3100 x 1560 x 2150 | 3511 |
Prod Model: |
60KVA~650KVA |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Engine Brand: |
Deutz |
Alternator Brand: |
Stamford, Leroy Somer, Victory |
Generator Control: |
Deepsea, Comaq, Smartgen |
Starting System: |
24V Electrical Free Maintenance Battery |
Fuel Tank: |
10 Hours Running Time for Full Load |
Governor Type: |
Electronic Type or Mechnical Type |
Voltage: |
AVR, 110V to 480V Are Available |
Breaker: |
MCCB Breaker |
Cooling System: |
50 Centigrade Radiator |
Warranty: |
1 Year or 1000 Hours, Earlier Time. |
Type: |
Micro-Computer Control Automatic Diesel Generator |
Installation Method: |
Fixed |
Stroke: |
Four Stroke |
Cooling Method: |
Water Cooling |
Output Type: |
AC Three Phase |
VICTORY POWER TECHNOLOGY Co., Limited is a professional manufacturer, specializing in production, design, sales, insallation, maintenance and service of generator sets with CUMMINS, PERKINS, DEUTZ, LOVOL, YANMAR, MTU, ISUZU, DOOSAN DAEWOO, Quanchai, Shangcai, Weichai, Yuchai, etc. Series world famous diesel engine and STAMFORD, LEROY SOMER, MARATHON series AC alternators. Victory series generator set power range is from 1kVA-2500kVA. We believe that it is our assurance of quality and exceptional communication skills in generation set field as well as our competitive prices and professional service that will always mean your best choice.
With great efforts and developments, we now have two Branch Companies. One is located in Guangdong, which mainly do some generator projects in China domestic market and responsible for international trade; The other factory is located in Fujian, as headquarters which mainly produce Cummins, Perkins, Deutz genset and Chinese brands gensets. Also, our own brand alternator are being made and exported to overseas countries at hunderds of thousands of units in a year.
Comply strictly with ISO9001: 2000 Quality System, our products have passed quite a lot of Certifications, including USA EPA, Europe CE, Argentina IRAM, Nigeria SONCAP, Kenya CoC, Tanzania CoC, Angola CNCA, Saudi Arabia SASO, etc. We always maintain the high quality of transmission and the standard of reliability, safety, durability as well as economy and environment-friendliness. And has formed a completed pre-sale, sale and after-sale service system.
As a team of about 300 staffs, including 30 engineers, a professional electromechanical enterprise full of enthusiasm is stepping toward its objectives---win customers with quality; Stand in the market with credit; Redound upon society with value; Call on innovation and humanism, try our best to serve customers base on novel design and integrated service!
Customers' satisfication, our traget!
