Model KT1500 KT1700 KT2500 KT2700 KT3500 KT3700 KT4500 KT4700 KT5500 KT5700 KT6500 KT6700 KT7500 KT7700
Generator Type Brushless Revolving Magnetic Field, Self-excitation, 2 poles, single-phase
Voltage Regulator Condenser type
Frequency (Hz) 50 60 50 60 50 60 50 60 50 60 50 60 50 60
MAX Output(kVA) 1.5 1.9 2.2 2.9 2.7 4.1 3.5 5 4.5 5.5 5.5 6 6 6.5
Rate Voltage(V) 110, 120, 220, 230, 240, 110/220, 120/240
Rate Output(kVA) 1.3 1.5 2 2.3 2.5 3 3 3.5 4 5 5 5.5 5.5 6
Power Factor cosφ =1.0
Engine Model KT168FA KT168FA KT168FB KT177F KT182F KT188F-1 KT190F
Type OHV, Forced air-cooled, 4 stroke
Displacement(ml) 163 163 196 270 337 389 389
Max Output 5.5HP/4000rpm 5.5HP/4000rpm 6.5HP/4000rpm 9.0HP/4000rpm 11HP/4000rpm 13HP/4000rpm 13HP/4000rpm
Fuel unleaded gasoline
Fule Tank Capacity(L) 11 11 11 17 17 17 17
Continous operating hours (h) 12.5 10.5 9.6 7.6 8 6 9.3 7.8 6.6 5.5 6.2 5 6.2 5
Oil SD or Higher
Oil Capacity (L) 0.6 0.6 0.6 1.1 1.1 1.1 1.1
Ignition System Transistor
Starting System Recoil Recoil/Electric Electrice
Noise Level(7m) dB(A) 64 66 65 68 65 68 67 70 70 73 71 74 71 74
Dimensions Net Dimensions LXWXH (MM) 555x420x470 630x495x490 655x510x490 675x510x490 675x510x490
Overall Dimensions LXWXH (MM) 571x436x500 650x515x530 675x530x530 695x530x530 695x530x530
Net Weight KG 38 41 43 65 76 79.5 86
Gross Weight KG 40 43 45 67 78 81.5 88
20FT (Unit) 210 210 210 150 145 140 140
Fujian Kete Electric Machinery Co., Ltd., established in 2006, is a manufacturer and exporter of portable gasoline generator sets, gasoline generator sets, diesel generator sets and various related motors. We produce 3, 000, 000PCS of generator sets a year.
