off Grid Solar Power System / Home Solar Power System 5kw
Features:
1. High reliability with guaranteed +/-10% output power tolerance
2. Tempered glass laminated with aluminum frame
3. Life time: 20-30 years
4. Temperature co-efficiency: A=+1, 46mA, B=-79mV, RP/p=0.43
5. Power specification at 1kw/m2
6. Output cable: Multi contact connectors
7. Diodes: Three 10A, 1KV schottky by pass diodes included
8. Construction:
A. Fromt high-transmission 32mm tempered glass
B. Back: TPT
C. Encapsulant: EVA
9. Frame: Aluminum alloy
10. Mono solar panel efficiency 17% and Poly solar panel 15%-16%
Off grid solar power supply system- SP-10KW |
System Basic Information | Solar panel rated output power: 10KW Suitable for daily power consumption: 32KWH Allowable max loads power: 12KW |
|
Solar panel | Type: polycrystalline or mono solar panel Max power: 200w Vmp: 36.8V Imp: 8.3A Size: 1498*998*40mm 25 years power output guarantee (CE TUV) | QTY 50pcs |
PV Array Combiner | Simplify wiring between PV array and controller, protections to controller, features: Wide range of DC input voltage Reliable thunderstorm& surge protection Multiple PV strings inputs Service time: 10 years, | QTY 2pcs | Notes: 1. pictures show are for reference. 2. power output data is based on areas with daily average peak power shine of 4.5hrs 3. the battery capacity is designed for power storage of 1.5-2 days PV output 4. solar panel rack can be specially designed based on site condition
Remark: 1)solar panel have 3 years warranty; 2)other parts have 2 years warranty; 3)ship the free parts for service(best service in china) 4)accept OEM |
Controller | Model: 96V80A PWM charging mode intelligent control., temperature compensation, various protection functions; | QTY 1pc |
Inverter | Pure sine wave inverter; 10kw DC input: 96v Output 110V/220v (optional) Use copper transformer; Bypass function with AC charger; LCD display | QTY 1pc |
Battery | Capacity; 12V/200AH Solar power lead-acid battery, full sealed Service life: 5-6 years, warranty: 2 year | QTY 40pcs |
Solar panel rack | Flat – roof type mounting rack, No welding/ cutting at site, easy mounting. More options to select: Slope-roof mounting rack Array type rack; Standing – pole type rack | QTY 1set |
Cables | International standard, with specification suitable for solar system, | 200m |
Foshan Tanfon Energy Technology Co., Ltd. is specialized in R&D, manufacturing and selling solar wind product and all kinds of pure sine wave inverter. As one of the leading factories in the green energy source field, Tanfon was initially established in the year of 1996. We are a professional manufacturer of green energy products including: Solar power system, wind power system, solar street light system, all kinds pure sine wave inverter(solar inverter, wind inverter, home UPS inverter ), controller, battery products., with advantage of possessing a professional R&D team to develop new wind energy turbine and inverter in concept of "Green Energy Leads Low Carbon Life".
Product sales to
(Pakistan, Nigeria, Canada, , Costa-Rica, Cyprus, Mocambique, Turkey, Malavi, Thiland, Philippines, Belgium, Indonesia, Czech Republic, Madagascar, Italy, Australia, Egypt, Tajikistan, Sri Lanka, Malaysia, France, USA, Guaemala, Switzerland, Israel ect)
We accept OEM and small trial orders, contacting with us for more information. All inquiries will be replied with in 24 hours. We also cordially welcome all clients to visit us and discuss business and place orders with us by any means of communication. We believe that with our best quality products and your marketing channel, we are certain to establish a lasting mutual beneficial cooperation relationship with you.
Good quality, best price and better technical support and service, make Tanfon energy technology Co., Ltd as your most valuable cooperator in China.
