Jiangsu GODLIKE Power Technology Co., Ltd (hereinafter referred to as "GODLIKE") is professional manufacturer of synchronous brushless alternators and diesel generating sets. Our workshop covers 100, 00sqm, and supply capacity can over 8000 units per year. And we are two hours away far from Shanghai port.
GODLIKE produces Stamford type brushless alternators, range from 8kVA to 1250kVA, 50Hz/60Hz option, rpm 1500-1800, voltage 110V-690V, class H, IP23, all easily coupled with Industrial&Marine, Diesel&Gasoline engines, world first-class of Cummins, Lovol, Volvo Penta, MTU, Deutz, MAN, Caterpillar, Yanmar, Kubota, Lister Petter, Doosan, etc, and our alternator are widely used in industry, commercial, real estate, hospital, hotel, railway, telecommunications, data-centers and mining etc.
GODLIKE people treat Quality and Service as enterprise's life, and has competitive advantages
1) Filters reliable suppliers with quality materials,
2) 100% quality copper wire, bearings, etc,
3) Strict Quality Control by QC. Dept.
4) comformity to IECBS 5000, VDE 0530, IEC 34, NEMA MG1-22, CSA C22.2-100 and ASB59.
Certified of CCC, CE, TUV, EPA, SGS
5) 2 years warranty-the first supplier who can offer in China.
6) Ships general parts within 3days upon customer's complaint
GODLIKE generators are being exported to Europe, America, Southeast Asia, the Middle East, South Africa, and many other countries and regions, obtaining great corporate reputation and long-terms partner cooperations.
Warmly welcome to GODLIKE
Catalogue of JDG series alternators |
Model | 50hz / 1500rpm/3 phase | 60 hz/ 1800rpm/ 3 phase |
190 - 454V | 110-240V/230-690V |
KVA | KW | KVA | KW |
JDG 164A | 8.1 | 6.5 | 10.2 | 8.2 |
JDG 164B | 11 | 8.8 | 13.8 | 11 |
JDG 164C | 13.5 | 10.8 | 16.9 | 13.5 |
JDG 164D | 16 | 12.8 | 20 | 16 |
JDG 184E | 22.5 | 18 | 30 | 24 |
JDG 184F | 27.5 | 22 | 35 | 28 |
JDG 184G | 31.3 | 25 | 37.5 | 30 |
JDG 184H | 37.5 | 30 | 46.9 | 37.5 |
JDG 184J | 42.5 | 34 | 50 | 40 |
JDG 224C | 42.5 | 34 | 55 | 44 |
JDG 224D | 50 | 40 | 65 | 52 |
JDG 224ES | 56.25 | 45 | 70 | 56 |
JDG 224E | 60 | 48 | 75 | 60 |
JDG 224F | 72.5 | 58 | 93 | 74.4 |
JDG 224GS | 80 | 64 | 100 | 80 |
JDG 224G | 85 | 68 | 103 | 82.4 |
JDG 224H | 94 | 75 | 115 | 92 |
JDG 274C | 100 | 80 | 125 | 100 |
JDG 274DS | 120 | 96 | 146 | 117 |
JDG 274D | 125 | 100 | 150 | 120 |
JDG 274ES | 140 | 112 | 178 | 142 |
JDG 274E | 150 | 120 | 187.5 | 150 |
JDG 274F | 160 | 128 | 206 | 165 |
JDG 274G | 190 | 152 | 225 | 180 |
JDG 274H | 200 | 160 | 255 | 204 |
JDG 274J | 230 | 184 | 300 | 240 |
JDG 274K | 250 | 200 | 312.5 | 250 |
JDG 314C | 250 | 200 | 320 | 256 |
JDG 314DS | 275 | 220 | 344 | 275 |
JDG 314D | 300 | 240 | 375 | 300 |
JDG314ESS | 312.5 | 250 | 387.5 | 310 |
JDG 314ES | 325 | 260 | 419 | 335 |
JDG 314E | 350 | 280 | 440 | 352 |
JDG 314FS | 380 | 304 | 475 | 380 |
JDG 314F | 400 | 320 | 500 | 400 |
JDG 354C | 450 | 360 | 594 | 475 |
JDG 354D | 500 | 400 | 644 | 515 |
JDG 354ES | 562.5 | 450 | 703 | 562.5 |
JDG 354E | 600 | 480 | 750 | 600 |
JDG 354FS | 625 | 500 | 738 | 590 |
JDG 354F | 670 | 536 | 825 | 660 |
JDG 354G | 700 | 560 | 862.5 | 690 |
JDG 404B | 750 | 600 | 938 | 750 |
JDG 404C | 800 | 640 | 1000 | 800 |
JDG 404D | 910 | 728 | 1138 | 910 |
JDG 404E | 1000 | 800 | 1250 | 1000 |
JDG 404F | 1125 | 900 | 1390 | 1112 |
JDG 404G | 1250 | 1000 | 1513 | 1210 |
Parameter |
Frequency: | 50Hz | 60Hz |
Power range: | 8-1250kva at 50Hz | 10-1500kva at 60Hz |
Rotational speed: | 1500rpm at 50Hz | 1800rpm at 60Hz |
Rated voltage: | 110-690V |
Insulation class: | H |
Temperature class: | H (can meet class F working and standby working) |
Bearing: | single bearing | two bearing |
Protection class: | IP23 |
Features: | 4 poles; AVR controlled; 12 wire reconnectable winding; 100% famous brand copper wire; 2/3 pitch windings avoid excessive neutral currents; dynamically balanced rotor and sealed-for-life bearings; 110% loading can work 1 hour every 12 hours; Permanent Magnet Generator(PMG) is available as an option; |
Terms |
MOQ: | 2 units |
Packing: | in strong plywood |
Color: | standard BAL7030 (according to the customer' s request) |
Load Port: | Shanghai Port, China |
Lead time: | about 7days(1 week); |
Warranty: | 2 years |
Established in Year 2006, GODLIKE POWER is headquartered in Yangzhou city, Jiangsu Province, only 2.5 hrs far from Shanghai or Nanjing. It has grown into a leading manufacture of diesel generators&alternators in China and ranked amongst the top manufacturers worldwide.
Motivated by our slogan to provide "Excellent Power Solution", Godlike Power focuses on design, manufacture, sales, installation and service of diesel generators&alternators. Our diesel generators range from 8 kVA to 2500 kVA, equipped with Perkins, Cummins, Mitsubishi, Doosan, Deutz, MTU etc and equipped with our alternator, Stamford, Leroy-Somer etc alternators as required. Our Stamford type brushless alternators range from 8kVA to 1250kVA, 50Hz/60Hz option, rpm 1500-1800, voltage 110V-690V, class H, IP23, all easily coupled with Industrial & Marine, Diesel & Gasoline engines.
GODLIKE people treat Quality and Service as enterprise's life, and has competitive advantages.
GODLIKE generators are being exported to Europe, America, Southeast Asia, the Middle East, South Africa, and many other countries and regions, obtaining great corporate reputation and long-terms partner cooperations.
Warmly welcome to GODLIKE.
