Main Features
1.145PSI/10bar High nitrogen pressuremake the unit a fit for almost any size automotive service facility **
2. Converts up to 6 tyres to Nitrogen simultaneously at the touch of a button **
3. Fully automated, fully programmable, micro-processor controlled conversion system
4. Suit for: Car, Light Truck, Bus
Technical Data Summary
Dimensions/Weight Main Body Tank
Height 1310mm/51.6" 1100mm/43.3"
Width 730mm/28.7" 400mm/15.7"
Depth 620mm/24.4" 400mm/15.7"
Net Weight 170kg/374.8lbs 38kg/83.8lbs
Gross Weight 207kg/456.4lbs 42kg/92.6lbs
Packing Size Main Body Tank
Height 1450mm/57.1" 1180mm/46.5"
Width 730mm/28.7" 440mm/17.3"
Depth 670mm/26.4" 440mm/17.3"
Power Requirement 100-240VAC 50/60Hz,
Power Consumption 70VA
Compressed Air Input Range 145-217PSI/10-15bar /1000-1500kPa
Nitrogen Purity 95-99+ %
Nitrogen Output 228L/min(8cfm)@116PSI/8bar/800kPa Absorption pressure
Maximum Nitrogen Pressure in Tank 145-174PSI/10-12bar/1000-1200kPa Adjustable
Operating Range 5-162PSI/0.3-11.2bar/35-1120kPa
Over Pressure Setting Range 0-29PSI/0-2.0bar/0-200kPa
Nitrogen Purges Cycles 0-9
Inflator Accuracy ± 1PSI/0.07bar/7kPa
Resolution 1PSI/0.1bar/5kPa
Specifications:
1. CMS Generator Generates nitrogen from your compressed air
2. Auto-start Auto-start inflation
3. Filter 2 Pre-Filters
4. Tank 118L/31.1gal(us)external nitrogen storage tank
5. OPS Adjustable over pressure setting(OPS)
6. N2P Nitrogen purge and fill cycle (N2P)
7. Purge cycle Adjustable number of cycles
8. Lower purge pressure limite Adjustable
9. Stardard inflation Standard inflate to target
10.6 tyres fill at one time 6 air outlets allow simultaneous inflation of up to 6 tires
11. Auto-start Auto-Start inflation
12. Zero drift Automatic zero drift adjustment
13. Setting Remain at last setting
14. Diagnostics Comprehensive diagnostics and error reporting
15. Signal indicators Audible and visual end of the cycle signal indicators
16. LCD display Large backlight LCD display
17. Switches Vandal resistant mechanical switches
18. Hose with chuck 4 Nos. *8M/26ft standard hoses with single clip-on closed chuck
Operation Steps
1. Set final target pressure using the + and - buttons. The LCD screen will show the target pressure.
2. Connect air hose(s) to tyre valve stem(s).
3. FOR TOP-OFF ONLY: Push the "FILL/PURGE" button once.
FOR NITROGEN CONVERSION: Push and hold the "FILL/PURGE" button for 2 seconds until the LCD screen shows "N2P".
4. When unit "beeps" and the LCD screen flashes the target pressure, tyre inflation is complete.
We Zhuhai EST Corporation is specialized in manufacturing Nitrogen Tyre Inflation System and Automatic Air Tyre Inflator with brand name of G5.
EST Corporation is one of the earliest PSA Nitrogen Tyre Inflation System manufacturer in the global market. EST Corporation is the technical leader in this industry.
There are more than 30, 000 clients in over 60 countries using G5 Nitrogen Tyre Inflation System throughout the world.
Our monthly production capacity in our 6, 000m2 factory reaches 800 Nitrogen Tyre Inflation Systems and 1000 Automatic Air Tyre Inflators.
Constantly Innovation, Enhance Versatility, Superior Performance are reflected in our products. We warmly welcome you, our esteem customers to place us G5-branded order or OEM and ODM orders.
