Working Principle
Under certain temperature,the residual oxygen in the low-purity nitrogen and the carbon provided by carbon catalytic generate CO2 after nitridation of C+O2=CO2.After removing the CO2 by PSA technique and further denitrification ,high-purity nitrogen is produced.
Technical Features
There is no H2 in it and it is suitable for use in the occasions which have strict requirement for H2 and O2.
High-efficiency and energy-saving technique makes the energy consumption of the system reduce greatly.
The deaerator adopts two-tower structure and adding and replacing of carbon catalytic agent can be done under non-stopping state.
Automatic venting device with national patented technology ensure s the quality of the produced nitrogen.
The key parts in the system adopt the famous brand,which is the effective guarantee of the equipment quality.
It ha s functions of diagnosis,alarming and automatic troubleshooting for several failures.
Technical Indexes
Nitrogen Output:10~500Nm³ / h
Nitrogen Purity : ≥ 99.9995%
Oxygen Content: ≤ 5 ppm
Carbon Dioxide Content: ≤ 1 ppm
Dew Point: ≤ -60 ºC
Model and Specification
THC-10
THC-20
THC-40
THC-60
THC-80
THC-100
THC-120
THC-160
THC-200
THC-250
THC-300
THC-400
Rated
Nitrogen Output(Nm³/h)
10
20
40
60
80
100
120
160
200
250
300
400
Rated Air Processing Amount Membrane Separation Nitrogen((Nm³/h)
11
22
44
66
88
110
132
176
220
275
330
440
Catalyst consumption amount(kg)
21.6
43.2
86.4
129.6
172.8
216
259.2
345.6
432
540
648
864
Installed Power(KW)
1.5
3
6
9
12
15
18
24
30
37.5
45
60
Cooling Water(t/h)
0.65
1.4
2.5
3.2
4.8
6.3
7.5
9.6
13.4
15.8
19.2
26.0
