Nitrogen Generator for Laser

Nitrogen Generator for Laser
Price: US $ 2000/Piece
Trade Terms: FOB,CIP
Min Order: 1/Piece
Pay Type: L/C,T/T
Brief Technical Parameters index
1. ) Nitrogen flow: 1-3000Nm3/h.
2. ) Nitrogen purity: 97-99.9995%.
3. ) Nitrogen pressure: 0.05-1.0 Mpa. (if need higher pressure, only to add the booster. )
4. ) Dew point: From -60 to -45 degree celsius.

Brief Introduction for PSA Nitrogen Generator Principles
When the process adopts lifting air, oxygen and nitrogen have different diffusion rate and adsorptive capacity to separate oxygen from nitrogen on carbon molecular sieve(CMS). When air is compressed to 0.8MPa, air source enters in pressure-swing adsorption tower for separation after being purified through dry and oil-water separation process (filter). Oxygen molecules are diffused and adsorbed in carbon molecular sieve under pressure. Non-adsorbed nitrogen is discharged from outlet of adsorption tower. Oxygen is desorbed, discharged and purged in adsorption tower under depressurization. Moreover, adsorbent can be recycled.

For Metallurgy Industries

For anneal protection, agglomeration protection, nitrogenizing, furnace washing and blowing, etc. Used in fields such as metal heating treatment, powder metallurgy, magnetic material, copper process, metallic mesh, galvanized wire, semiconductor, etc.

Specification
1. Place of Origin: Jiangsu, China.
2. Brand Name: TRUE.
3. Model No.: TY395-220
4. Color: Silver, bright and white.
5. Nitrogen flow: 220Nm3/h.
6. Nitrogen purity: 99.95%.
7. Dew point: -45 degree Celsius.
8. Warranty period: One and a half years.
9. Product life: At least 10years or longer.
10. Outlet pressure: 0.05-1.00Mpa.
11. Material: Steel.
12. Packaging details: Standard, if need wooden, will charge for cost.
13. Delivery time: Within 10days, when received 50% advance payment.

Type & Modles

                                                                    Main Parameters

Nitrogen flow  ( Nm³/h)

Air consumption ( m³/h)

Air pressure

Purity

Shape and dimension (L*W*H mm)

Voltage

Weight

TY395-100

100

7.5

0.8-1.0Mpa

≥ 99.95%
3300*2600*2800
220V50HZ

1800 kg

TY395-200

200

15

0.8-1.0Mpa

≥ 99.95%

3300*2800*2900

220V50HZ

2500 kg

TY395-300

300

17.5

0.8-1.0Mpa

≥ 99.95%

3500*2800*2900

220V50HZ

3000kg

TY395-400

400

23.5

0.8-1.0Mpa

≥ 99.95%

3500*2800*2900

220V50HZ

3500kg

TY395-500

500

29.2

0.8-1.0Mpa

≥ 99.95%

3500*2800*2900

220V50HZ

4000kg

TY395-600

600

35

0.8-1.0Mpa

≥ 99.95%

3600*3000*2900

220V50HZ

4500kg

TY395-800

800

46.7

0.8-1.0Mpa

≥ 99.95%

4200*3000*3000

220V50HZ

5500kg

TY395-1000

1000

58.5

0.8-1.0Mpa

≥ 99.95%

4300*3200*3000

220V50HZ

6000kg

TY395-1500

1500

87.5

0.8-1.0Mpa

≥ 99.95%

4500*3600*3000

220V50HZ

7000kg

TY395-2000

2000

117

0.8-1.0Mpa

≥ 99.95%

5000*4000*3000

220V50HZ

7500kg

TY395-3000

3000

175

0.8-1.0Mpa

≥ 99.95%

7000*6000*3000

220V50HZ

8000kg

Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type: Nitrogen Generator
Product Type: Nitrogen Generator
Usage: Air Separation
Jiangyin Tongyue Machinery Equipment Co., Ltd is located in the top 100 county-level economic, China most economic vitality charm city, national harmonious city, a national chemical coatings, printing ink machines R&D, finishing set base - jiangyin city, jiangsu. Backed by the Yangtze river; In accordance with the Beijing-Shanghai expressway, near Shanghai-nanjing expressway jiangyin section, jinghu railway changzhou station; Lateral adjacent shenzhen airlines wuxi bosoar put airport, changzhou bull-running airport, from home and abroad friends from various circles to enterprise investigation, making friends give very convenient traffic position.

The company specialized production (PSA) carbon nitrogen making machine, molecular sieve nitrogen purification devices, widely used in food, medicine, chemical industry, chemical fiber, metallurgy heat treatment, electronic and etc, equipment with compact structure, high automation, stable performance, low energy consumption, low noise, no pollution, etc.
