Detailed Product Description
1) Runoff: 50-80Nm3/h
2) Purity: 97-99.9%
3) Pressure: 0.65Mpa
4) ISO-9000
Technical indexes
1) Nitrogen runoff: 50-80Nm3/h
2) Nitrogen purity: 97-99.9%
3) Nitrogen pressure: 0.65 Mpa
4) Dew point: -45oC
5) Purification not needed, as nitrogen 99.995% purity is produced
Principle of CMS(Carbon Molecular Sieve)Nitrogen Generations
When the process adopts lifting air, oxygen and nitrogen have different diffusion rate and adsorptive capacity to separate oxygen from nitrogen on carbon molecular sieve. When air is compressed to 0.8MPa, air source enters in pressure-swing adsorption tower for separation after being purified through dry and oil-water separation process (filter). Oxygen molecules are diffused and adsorbed in carbon molecular sieve under pressure. Non-adsorbed nitrogen is discharged from outlet of adsorption tower. Oxygen is desorbed, discharged and purged in adsorption tower under depressurization. Moreover, adsorbent can be recycled.
Main Applications of Nitrogen Generator
1. Metallurgy: For anneal protection, agglomeration protection, nitrogenizing, furnace washing and blowing, etc. Used in fields such as metal heating treatment, powder metallurgy, magnetic material, copper process, metallic mesh, galvanized wire, semiconductor, etc.
2. Chemical and new material industries: For chemical material gas, pipeline blowing, gas replacement, gas protection, product transport, etc. Used in fields such as chemical, urethane elastic fiber, rubber, plastic, tyre, polyurethane, biological technology, intermediate, etc.
3. Electronic industry: For encapsulation, agglomeration, anneal, deoxidization, storage of electronic products. Used in fields such as peak welding, circumfluence welding, crystal, piezoelectricity, electronic porcelain, electronic copper tape, battery, electronic alloy material, etc.
Features of Nitrogen Making Machinery
Full Automation
All systems are designed for unattended operation and automatic Nitrogen demand adjustment.
Low Electric Energy Consumption
All systems are designed for Energy-Efficient.
Lower Space Requirement and Short installation period
The design and Instrumentation makes the plant size very compact, assembly on skids, prefabricated and supplied from factory.
Installation is very easy and convenient.
Fast Start-Up
Start-up time is about 30 minutes to get desired Nitrogen purity. So these units can be switched ON & OFF as per Nitrogen
Demand changes.
High Reliability
Very reliable for continuous and steady operation with constant Nitrogen purity. Plant availability time is better than 98% always.
Molecular Sieves Life
Expected Molecular sieves life is more than 10-years i. e. Whole life time of Nitrogen plant. So no replacement costs.
Simple operation and maintenance
All systems are designed by integrated solution for easy-operation and easy-maintenance.
|
Place of Origin: |
Jiangyin, China (the People' s Republic of China) |
|
Brand Name: |
TURE |
|
Model Number: |
TY-200 TY-300 TY-400 TY-500 |
|
Usage: |
Nitrogen |
|
Production Rate: |
200-500 |
|
Color: |
Silver, bright, and white |
|
Nitrogen purity: |
95%-99.995% |
|
Nitrogen runoff: |
200-500Nm3/h |
|
Dew point: |
-45 degree Celsius |
|
Product life: |
At least 10 years or longer |
|
Warranty period |
one and a half years |
|
Outlet Pressure: |
0.65Mpa |
|
Material: |
Steel |
|
Characteristics: |
Special pressure device |
|
Application: |
Industry, GMP, Aquaculture, Beverage etc. |
|
Usage: |
Nitrogen |
|
Port: |
Shanghai |
|
Packaging Details: |
Standard |
|
Delivery Time: |
30days |
Jiangyin Tongyue Machinery Equipment Co., Ltd is located in the top 100 county-level economic, China most economic vitality charm city, national harmonious city, a national chemical coatings, printing ink machines R&D, finishing set base - jiangyin city, jiangsu. Backed by the Yangtze river; In accordance with the Beijing-Shanghai expressway, near Shanghai-nanjing expressway jiangyin section, jinghu railway changzhou station; Lateral adjacent shenzhen airlines wuxi bosoar put airport, changzhou bull-running airport, from home and abroad friends from various circles to enterprise investigation, making friends give very convenient traffic position.
The company specialized production (PSA) carbon nitrogen making machine, molecular sieve nitrogen purification devices, widely used in food, medicine, chemical industry, chemical fiber, metallurgy heat treatment, electronic and etc, equipment with compact structure, high automation, stable performance, low energy consumption, low noise, no pollution, etc.
Innovation and honesty is the company eternal rules
