1)About our Company :We are the generator factory since 2003 year, have more than 13years experience ,
We offer best quality products to our clients with the best price
2) Generator technology Portable Silent Diesel Generator 5kVA
HAIGE DG6700SE super silent diesel generator powered by 418cc, 10HP air cooled, single cylinder, 4-stroke, direct injection diesel engine DE186FAE.
Characteristics:
1) Powered by air-cooled 4-stroke direct injection diesel engine
2) Its advanced direct fuel injection adopting minimized pump and nozzle insures long life and provides for low fuel consumption, easy starting, quiet running.
3) Dynamic balancer reduces the vibration to a minimum and mades its running more stable and smoothly
4) No fuse circuit breakers for overload protection and convenience
5) Large silent muffler and balancer shaft inside and high efficient noise-proof materials, vibrations, reducing structure combine to form a silent machine
6) Large fuel tank ensures hours of continuous running
| Model | DG7500SLE | DG7500SLE-3 |
| Frequency(Hz) | 50 | 60 | 50 | 60 |
| Max. power(kva) | 5.0 | 5.0 | 5.5 | 6.3 |
| Rated power(kva) | 4.5 | 5.5 | 6.0 | 7.0 |
| Voltage(V) | 220;230;240 | 220/380; 230/400; 240/415 |
| Engine speed(rpm) | 3000 | 3600 | 3000 | 3600 |
| Phase | Single | Three |
| Power factor | 1.0 | 0.8 |
| Excitation system | Self-excited vonstant voltage(AVR) |
| Noise level dB(A)@7m | 72 |
| Fuel tank capacity(L) | 15L |
| DC Output(V/A) | 12/8.3 |
| Net weight(kg) | 168 | 170 |
| Dimensions(mm) | 925*545*720 |
| Engine model | DE186FAE |
| Engine type | Single cylinder, vertical, 4-stroke, air-cooled, direct injection |
| Bore*stroke(mm) | 86*72 |
| Displacement(cc) | 418 |
| Engine power(kw) | 5.7 | 6.3 | 5.7 | 6.3 |
| Fuel consumption rate(g.kw/h) | 275.1 | 281.5 | 275.1 | 281.5 |
| Container Qty. | 36pcs/ 20ft; 144pcs/ 40ft |
| Lube oil capacity(L) | 1.65 |
Control panel and ATS (Auto Transfer Switch)for optional
- Overload protection through intensity control LED display.
- Leakage breaker 30mA for machine and person protection.
- Pre heating system for easier starting in cold conditions.
- LED digital display 4 functions.
- Emergency STOP button.
- DC 12v output 8,3A.
- Earth connection.
- ATS automatic start in Electric start models with optional Remote Control and Timmer.
Fuzhou Haige M&E Co., Ltd. is engaged in research, development, manufacture and selling in various kinds of Engine, Generator, Water Pump, Generating Welder, Mobi Light Tower, Rotary Tiller and other power equipment, electric components industrial plug and socket.
The company was founded in 2003 with 15, 000 m2 workshop and employs more than 200 staff workers, among which 50 are engineers or technicians. It operates an advanced production line with whole set of inspection and testing equipment and a yearly capacity of 300, 000 sets of machines exported worldwide. The company put through EPA, CE, GS and ISO9001 Certificate.
The company employs only fully qualified personnel to deal with all aspects of sales and service of generators, also holds a large and varied stock of Generating Sets (gensets) and a full range of parts for generators and spares for generators available. The Generating Sets (gensets) from 2kVA to 800kVA suitable for all applications including Supermarkets, Hotels, Factories, Schools and Fleet Rental.
"Reputation is the first, Consumers are supreme" is our persistent working tenet. We will keep a high standard for a valued added service to our international customers and will serve the consumers with high quality, reasonable price, perfect service and flexible working way.
