Product name:
Neodymium magnets
NdFeB,the third generation of rare-earth permanent magnet, is the most powerful and advanced permanent magnet today.NdFeB is named as "magnet king" for its high remanence, high coercive force, high energy.Moreover, it has the high performance and high cost ration, because of the rich rare earth resources in China and the ever-changing production process and technological progress .It can be easily formed into various sizes and different shapes, such as segment, ring, block and etc.
Nowadays, it has been widely used in fields such as aviation, electronics, instruments, meters, machine, medical instrument or something like that, it's especially the best choice for various motors, as its thermal stability, along with the improvement of its corrosion resistance and the further development of power electronic device .At present, rare permanent magnet motor has become one of leading trends in the motor development.
Specification:
1.Product::Neodymium magnet
2.Shape:Ring,square,Arc,Cylinder,etc
3.Printing:None
4.Size:Customize
5.Packing:Pallet, carton
6.Delievery time:20-35days after you order, according to the quantity of magnet
Features:
1.High Remanence ,high coercive force,high ennergy;etc
2.Can do any shape
3.High cost -performance
4.Not suitable for application which exposed to high temperatures.Maximal operating temperature
Is 220 degree.
5.Superior demagnetization
Process Flow of sintered NdFeB
Pre-sintered material inspection ----Secondary Fine Milling----Molding----Sintering----Surface Grinding and
Cleaning----Inspection and Selection----Packing----Inspection Before Warehousing----Warehousing-----
Final Aduit----Delievery
Advantages:
1.OEM accepted:We can produce any design from you
2.Perfect after sale service
3.High quality control
4.Competitive price
5.Experienced in this field for years.(quality, price, packing, etc)
6.High remanence, high coercive force, high energy, etc
7.Excellent cost to performance ratio
8.Can be any shape
Usage
Widely used in mini-motors, wind generators, meters, sensors, speakers, magnetic suspension system, magnetic transmission machine and other industrial applications.
About Sintered Neodymium Magnet
Since the foundation of our company in 2005, we have been engaged in the manufacturing and distributing of magnetic materials.At present, we are capable of producing 220 tons of NdFeB per year and our annual sales rises to 6 million dollars.Our products are mainly exported to Europe, America and Southeast Asia.Half of our products are purchased by American or German loudspeaker manufacturers, such as the JBL and AR in the US as well as the Heco in Germany.Thirty percent are sold to electric machine manufacturers like the Italian Cear and the Chinese Baolai.We have earned good reputation in this industry and established long-term cooperative relationship with multiple clients.
Our product features high quality-price ratio.With superior mechanical properties, it is easy to cut and process.The defects of the sintered neodymium magnet lie in the low Curie temperature, poor temperature characteristics, and high susceptibility to pulverization.We have provided solutions to remedy those flaws by adjusting the chemical composition and electroplating the surface.The product we offer can pass the 72-hour salt spray test and its maximum operating temperature reaches 240ºC, thus satisfying the practical application requirements.
Our sintered neodymium magnet has been widely used for the cell phone headsets, high-end loudspeaker boxes, permanent magnet motors, micro motors, gift boxes, handbags, toys, medical instrumentations, instruments and apparatus, metal and plastic products, electronic components, electric car motors, wind turbine generators, and many other items.
Inquires from you are always warmly welcomed.Thanks !
Technical Specifications of Sintered Neodymium Magnet |
Grade |
Remanence Br
mT (KG) |
Coercive Force Hcb
KA/m (KOe) |
Intrinsic Coercive Force Hcj
KA/m (KOe) |
Maximum Energy Product BHmax
KJ/m3 (MGOe) |
Maximum Operating Temperature Tw
ºC |
N35 |
1170-1220(11.7-12.2) |
≥868(≥10.9) |
≥955(≥12) |
263-287(33-36) |
80ºC |
N38 |
1220-1250(12.2-12.5) |
≥899(≥11.3) |
≥955(≥12) |
287-310(36-39) |
80ºC |
N40 |
1250-1280(12.5-12.8) |
≥907(≥11.4) |
≥955(≥12) |
302-326(38-41) |
80ºC |
N42 |
1280-1320(12.8-13.2) |
≥915(≥11.5) |
≥955(≥12) |
318-342(40-43) |
80ºC |
N45 |
1320-1380(13.2-13.8) |
≥923(≥11.6) |
≥955(≥12) |
342-366(43-46) |
80ºC |
N48 |
1380-1420(13.8-14.2) |
≥923(≥11.6) |
≥876(≥12) |
366-390(46-49) |
80ºC |
N50 |
1400-1450(14.0-14.5) |
≥796(≥10.0) |
≥876(≥11) |
382-406(48-51) |
60ºC |
N52 |
1430-1480(14.3-14.8) |
≥796(≥10.0) |
≥876(≥11) |
398-422(50-53) |
60ºC |
35M |
1170-1220(11.7-12.2) |
≥868(≥10.9) |
≥1114(≥14) |
263-287(33-36) |
100ºC |
38M |
1220-1250(12.2-12.5) |
≥899(≥11.3) |
≥1114(≥14) |
287-310(36-39) |
100ºC |
40M |
1250-1280(12.5-12.8) |
≥923(≥11.6) |
≥1114(≥14) |
302-326(38-40) |
100ºC |
42M |
1280-1320(12.8-13.2) |
≥955(≥12.0) |
≥1114(≥14) |
318-342(40-43) |
100ºC |
45M |
1320-1380(13.2-13.8) |
≥955(≥12.5) |
≥1114(≥14) |
342-366(43-46) |
100ºC |
48M |
1360-1430(13.6-14.3) |
≥1027(≥12.9) |
≥1114(≥14) |
366-390(46-49) |
100ºC |
50M |
1400-1450(14.0-14.5) |
≥10339(≥13.0) |
≥1114(≥14) |
382-406(48-51) |
100ºC |
35H |
1170-1220(11.7-12.2) |
≥868(≥10.9) |
≥1353(≥17) |
263-287(33-36) |
120ºC |
38H |
1220-1250(12.2912.5) |
≥899(≥11.3) |
≥1353(≥17) |
287-310(36-39) |
120ºC |
40H |
1250-1280(12.8-12.8) |
≥923(≥11.6) |
≥1353(≥17) |
302-326(38-41) |
120ºC |
42H |
1280-1320(12.8-13.2) |
≥955(≥12.0) |
≥1353(≥17) |
318-342(40-43) |
120ºC |
45H |
1300-1360(13.0-13.6) |
≥963(≥12.1) |
≥1353(≥17) |
326-358(43-460 |
120ºC |
48H |
1370-1430(13.7-14.3) |
≥955(≥12.5) |
≥1353(≥17) |
366-390(46-49) |
120ºC |
35SH |
1170-1220(11.7-12.2) |
≥876(≥11.0) |
≥1592(≥20) |
263-287(33-36) |
150ºC |
38SH |
1220-1250(12.2-12.5) |
≥907(≥11.4) |
≥1592(≥20) |
287-310(36-39) |
150ºC |
40SH |
1240-1280(12.5-12.8) |
≥939(≥11.8) |
≥1592(≥20) |
302-326(38-41) |
150ºC |
42SH |
1280-1320(12.8-13.2) |
≥987(≥12.4) |
≥1592(≥20) |
318-342(40-43) |
150ºC |
45SH |
1320-1380(13.2-13.8) |
≥1003(≥12.6) |
≥1592(≥20) |
342-366(43-46) |
150ºC |
30UH |
1080-1130(10.8-11.3) |
≥812(≥10.2) |
≥1990(≥25) |
223-247(28-31) |
180ºC |
33UH |
1130-1170(11.3-11.7) |
≥852(≥10.7) |
≥1990(≥25) |
247-271(31-34) |
180ºC |
35UH |
1180-1220(11.8-12.2) |
≥860(≥10.8) |
≥1990(≥25) |
263-287(33-36) |
180ºC |
38UH |
1220-1250(12.2-12.5) |
≥876(≥11.0) |
≥1990(≥25) |
287-310(36-39) |
180ºC |
40UH |
1240-1280(12.5-12.8) |
≥899(≥11.3) |
≥1990(≥25) |
302-326(38-41) |
180ºC |
28EH |
1040-1090(10.4-10.9) |
≥780(≥9.8) |
≥2388(≥30) |
207-231(26-29) |
200ºC |
30EH |
1080-1130(10.8-11.3) |
≥812(≥10.2) |
≥2388(≥30) |
223-247(28-31) |
200ºC |
33EH |
1130-1170(11.3-11.7) |
≥836(≥10.5) |
≥2388(≥30) |
247-271(31-34) |
200ºC |
35EH |
1170-1220(11.7-12.2) |
≥876(≥11.0) |
≥2388(≥30) |
263-287(33-36) |
200ºC |
38EH |
1220-1250(12.2-12.5) |
≥899(≥11.3) |
≥2388(≥30) |
287-310(36-39) |
200ºC |
28AH |
1020-1080(10.2-10.8) |
≥780(≥9.8) |
≥2704(≥34) |
199-231(25-29) |
240ºC |
30AH |
1020-1080(10.2-10.8) |
≥811(≥10.2) |
≥2704(≥34) |
223-247(28-29) |
240ºC |
N35T |
1170-1210(11.7-12.1) |
≥868(≥10.9) |
≥955(≥12) |
263-287(33-36) |
80ºC |
N45T |
1320-1380(13.2-13.8) |
≥876(≥11.0) |
≥955(≥12) |
342-366(43-46) |
80ºC |
N48T |
1380-1420(13.8-14.2) |
≥836(≥10.5) |
≥876(≥11) |
366-390(46-49) |
80ºC |
35MT |
1170-1210(11.7-12.1) |
≥868(≥10.9) |
≥1114(≥14) |
263-287(33-36) |
100ºC |
45MT |
1320-1380(13.2-13.8) |
≥995(≥12.5) |
≥1114(≥14) |
342-366(43-46) |
100ºC |
38HT |
1210-1250(12.1-12.5) |
≥899(≥11.3) |
≥1353(≥17) |
287-310(36-39) |
120ºC |
40HT |
1240-1280(12.4-12.8) |
≥923(≥11.6) |
≥1353(≥17) |
302-326(38-41) |
120ºC |
45HT |
1320-1380(13.2-13.8) |
≥995(≥12.5) |
≥1353(≥16) |
342-366(43-46) |
120ºC |
35SHT |
1170-1210(11.7-12.1) |
≥876(≥11.0) |
≥1592(≥20) |
263-287(33-36) |
150ºC |
38SHT |
1210-1250(12.1-12.5) |
≥907(≥11.4) |
≥192(≥20) |
287-310(36-39) |
150ºC |
42SHT |
1280-1320(12.8-13.2) |
≥995(≥12.5) |
≥1592(≥20) |
318-342(40-43) |
150ºC |
L-30SHT |
1080-1130(10.8-11.3) |
≥804(≥10.1) |
≥1592(≥20) |
223-247(28-31) |
150ºC |
L-33SHT |
1130-1170(11.3-11.7) |
≥844(≥10.6) |
≥1592(≥20) |
247-271(31-34) |
150ºC |
L-35SHT |
1170-1210(11.7-12.1) |
≥876(≥111.0) |
≥1592(≥20) |
263-287(33-36) |
150ºC |
L-38SHT |
1210-1250(12.1-12.5) |
≥907(≥11.4) |
≥1592(≥20) |
287-310(36-39) |
150ºC |
L-30UHT |
1080-1130(10.8-11.3) |
≥812(≥10.2) |
≥1990(≥25) |
223-247(28-31) |
180ºC |
L-33UHT |
1130-1170(11.3-11.7) |
≥852(≥10.7) |
≥1990(≥25) |
247-271(31-34) |
180ºC |
L-38UHT |
1210-1250(12.1-12.5) |
≥907(≥11.4) |
≥1990(≥25) |
287-310(36-39) |
180ºC |
L-30EHT |
1080-1130(10.8-11.3) |
≥812(≥10.2) |
≥2388(≥30) |
223-247(28-31) |
180ºC |
Xiamen magnet forever electronics Co., Ltd as one of the professional manufacturer which is a collection of magnetic material research, development, production and sales. Our sales headquarters is located in the beautiful environment civilized city of Xiamen. Production base is located in China magnetic city of Zhejiang. Our company in line with the pursuit of excellence, improve the details of quality approaches and attitudes, communication-oriented business philosophy to provide satisfactory magnetic products and services for clients all over the world. We have the perfect testing equipment, reliable technical team and the enthusiastic sales team, may according to the customer' S request with the development of new products and provide samples. Our products are widely used in speakers, motors, medical, sensors, sports equipment, aerospace, handicraft and toys, etc. Welcome to contact our company for price, samples and factory inspection. We are looking forward to your visit.
Buyer Guide
Grade, shape & size, tolerance, coating requirement, magnetize direction, quantity are necessary details for a good quotation.
Please send us drawing or special packing demand to make things clear if the magnet would be particularly customized.
Trading Conditions
1. Sample: Samples are available to test.
2. Shipment terms: There are two shipping methods, one is by sea, and another is by express, including DHL(it'spriority),
UPS, FedEx, TNT, etc.
3. Packing methods: Demagnetize packing box (for Air and Express) and normal packing box for sea.
Details: PCS/CTN, CTNS/PLT, CTNS/Wooden carton, PLTS/Container
