1. Easy to start (within 3-5 times for recoil starter, within 30S for electric starter)
2. Stable (voltage and frequency fluctuate smoothly)
3. Clear, Lower emission(no smoke, no smell, good protection for your health and environment)
4. Cost saving (save 30%~70% operation cost than oil powered generator set)
5. Longer serving life (25% longer than gasoline oil powered generator set )
6. Safety and Convenience for operation (The only way to close the generator is to cut off the gas which make the operation safe. )
7. Easy for maintenance
Model YGP2500L YGP3000LX YGP5000LX YGP6500LX YGP8000LX
GENSET Type Brushless, Revolving Magnetic Field, Self-excitating, 2 Poles
Voltage Regulator Condenser Type
Frequency HZ 50 60 50 60 50 60 50 60 50 60
Max. AC Output KVA 2.3 2.5 2.8 3 4.5 5 5.5 6.5 8.5 9.5
Rated AC Voltage V 110, 120, 220, 230, 110/220, 120/240
Rated AC Output KVA 2 2.3 2.5 2.8 4 4.5 5 5.5 8 8.5
Power Factor cosφ cosφ=1
ENGINE Model YL168FC YL169FC YL182FEC YL188FEC YL190FEC
Type Forced Air-cooled, $-stroke, OHV
Displacement ml 163 196 337 389
Max. Output 5.5HP/4000rpm 6.5HP/3600rpm 11HP/4000rpm 13HP/4000rpm 15HP/4000rpm
Fuel Natural Gas, LPG, Marsh Gas (Unleaded Gasoline)
Compression Ratio 8: 01
Fuel Tank Capacity l 12 22
Continuous. Hours h 11 9.5 10 9 9.2 9.5 8.2 7 8 7
Oil Engine Oil SD or Higher
Oil Capacity l 0.6 0.6 1.1 1.1 1.1
Ignition System T. C. I
Starting System Recoil Recoil-self
Noise Level (7m) dB 65 68 65 68 70 73 72 75 72 75
DIMENSION Net L*W*H mm 545*425*440 565*425*440 674*510*532
Package L*W*H mm 560*440*460 580*440*460 700*530*550
N. W/G. W kg 43/45 45/48 75/78 84/87 87/90
20FT unit 265 225 140 140 140
Yalai is a professional manufacturer of air-cooled diesel engines, gasoline engines, water pumps, atomizing pumps and generator sets. It enjoys convenient transportation and beautiful environment. Of more than 100 employees, senior and medium technicians take up to 60 percent. Equipped with advanced assembly lines, CNC processing center and test facilities, Yalai can realize 36, 000 units/sets annual output and has passed the quality control system certification ( SGS )and safety certification(most of our products has passed EPA & CE approva). Of course YALAI has the power of management over import and export businesses authorized by Ministry of Commerce...Thanks to reliable quality and competitive price, the products are sold to more than 70 countries and regions.
