Product Description
Welcome to the showroom of Shandong Chaiwei Power Equipment Co., Ltd!
We are professional and dedicated system supplier of energy production by diesel and gaspowered generator set for almost 20 years, we are basically a manufacturer of generator set for various kinds of fuel such as diesel, natural gas, biogas, biomass gas, coal gas, coal bed gas(CBM), associated gas and syngas.
Main spare parts:
Ignition system: American ALTRONIC, including:magneto, high-tension coil,
Starting system: DC24V electric motor.
Mixer: IMPCO
Sparking plug: STITT
scope of application: Biomass gas produced by biomass gasifier, the raw material could be wood, rice husk, straw, nut shell and so on.
Worksite requirements
The worksite needs to meet following basic requirements:
a) Ambient temperature between -40ºC~40ºC;
b) Relative humidity less than 95%(35ºC);
c) Site elevation not higher than 2500m;
d) For outdoor installation, simple rain shelter is required.
Gas requirements
1m from genset's pressure regulating valve of inlet
1. Pressure of natural gas: 80~300kPa
2. CH4 content of natural gas≥70%
3. H2S≤20mg/Nm3
4. Impurities particle size≤5μm, impurity content≤30mg/Nm3
Purification of natural gas has a significant impact on machine life and continuous running time!
Service committee
1. Pre-sale service:
1) We will send our engineer to prospect the site of power station free of charge.
2) According to the situation of site, we will provide design drawings, such as power plant floor drawing, cooling system drawing, genset foundation, control room design, etc.
2. Sale service:
1) Operator training would be conducted by Chaiwei technicians during the process of commissioning or Factory training course in China,
2) Installation and commission of the genset would be instructed assisted by Chaiwei technicians at site.
3. After-sale service:
1) We have strong after-sale team, we will response within 24 hours and provide technical supports by phone or site guiding, help our clients to gain the biggeset profit.2) For the quality problem, we will service for you free of charge during the guarantee period.3) We provide one year guarantee period and lifetime service.Plentiful spare part supply1. We have spart parts department, plentiful spare part supply for all genset model will guarantee genset lifetime running.2.All parts were from original factories or professional factories,complete in specification,keep good quality Main technical datas for 500kw natural gas generator set |
Manufacturer | | Shandong Chaiwei Power Equipment Co., Ltd |
Genset model | | CW-500GFT |
Engine model | | G12V190ZLDT-2 |
Alternator model | | 1FC6 455-6LA42 |
Field control panel | | PFT-500 |
Prime power | kW | 500 |
Rated current | A | 902 |
Rated voltage | V | 400/230 |
Rated power factor | cosφ | 0.8 (lagging) |
Frequency | HZ | 50 |
Fuel gas consumption | MJ/(kW@h) | 9.8 |
Lubricant consumption | g/(kW@h) | ≤1.0 |
Start-up method | | DC 24V Electric motor |
Start-up control | | Manual/Automatic |
Wiring method | | 3 phase 4 line |
Stable speed droop | % | ≤5 |
Cooling method | | Closed loop, with fan radiator |
Exhaust back pressure max. | | 6 kPa |
Noise level | | 106 db @ 1 meter away from the genset |
Genset vibration | | ≤7.2mm/s |
Coupling between engine and alternator | | Elastic coupling |
Dimension (L×B×H) | mm | 6200x2100x2800mm |
Remote fan cooler | mm | 4100*1800*2200mm |
Weight of genset | kg | 12500 |
Optional generator sets
open type ,silent type , Container type, trailer type
For open type, the genset will be much easier to maintainance and repair, with more durable performance and longer service life, so the cost performance is higher.
For silent type, generator set, the noise level can be 70-75db(A)@7M; with silent canopy, the genset can be soundproof, rainproof, rustproof, dustproof and more safe.
Why choose us?
20years professional expericence to produce genset
Short product cycle(15days average)
Generator is solid and compact
High efficiency ,low cost
Low daily maintenance costs
Good after-sale service
Welcome visit our factory and contact us.
