Generator Options, Control Panels, Remote Monitoring, and Attachments
HUALING GAS Power provides a full line of options and attachments to customize your Generator Set to fit your exact needs.
For a complete list and specifications, please us:
Generator Options Include:
Anti-Condensation Heater
Excitation System
Permanent Magnet Generator
Voltage Regulator
Generator Control Systems & Monitoring Options Include:
Auto-start Control Panel
Auxiliary Controls
Digital Control Panel
Electronic Governor
Key start Control Panel
Load Sharing
Remote Annunciator
Remote Monitoring Software
Shunt Trip
Single / Dual Circuit Breakers
Speed Control
Generator Accessories Include:
Battery Heater
Coolant Heater
Engine Exhaust System
Exhaust Silencer / Muffler
External Fuel Tank
High Output Battery
Integrated Fuel Tank Base
Lube Oil Drain Pump
Lube Oil Sump Heater
Seismic Vibration Isolator
Sound Attenuated Enclosure
Static Battery Charger
Sub-base Fuel Tank
Weatherproof Enclosure
HUALING POWER GAS GENERATOR SPECIFITIONS |
Air pressure 100kpa ,
ambitent temperature 25c
and humid is 30%,
the engine can work 12hours
and work efficiary can up to 90% |
Generator Model |
HL20GF |
HL24GF |
HL25GF |
HL50GF |
HL64GF |
HL75GF |
HL90GF |
HL100GF |
HL120GF |
HL132GF |
HL150GF |
HL165GF |
HL180GF |
Rated Power kw |
20 |
24 |
25 |
50 |
64 |
75 |
90 |
100 |
120 |
132 |
150 |
165 |
180 |
Engine Model |
HL493CNG(ISUZU) |
HL6102CNG-D(6BT)(CUMMINS) |
HL6126CNG-D. (STEYR) |
Type |
Four stroke In-line four-cylinder Water cooling Electric ignition Doing-like thin wall chromium plating cylinder liner |
Four stroke In-line six-cylinder Water cooling Booster Intercooler Single Poine Electronic Fuel Injection Doing-like thin wall chrome-plating cylinder liner |
Four stroke In-line six-cylinder Water cooling Booster Intercooler Single Poine Electronic Fuel Injection Doing-like thin wall chrome-plating cylinder liner |
Rated power kw |
24 |
28 |
30 |
60 |
78 |
90 |
110 |
120 |
144 |
158 |
180 |
198 |
216 |
Rated speed r/min |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
Idle r/min |
800± 50 |
Power factor |
0.8 |
m3/kw. hHeat consumption |
≤ 0.22 |
Excitation Mode of the power generator |
Brushless |
Oil consumption |
≤ 1.36g/KW· h |
Grounding of the power generator |
Three Phase Four Wires |
Front row of turbinetemperature |
≤ 650c |
Insulation class |
F |
Rated Voltage |
400V |
Rated Frequency |
50Hz |
Voltage |
Regulation of steady-state ≤ ± % Regulation of the transient≤ ± 20% Stabilization time ≤ ± 1.5s Volatility ≤ ± 0.8% |
Frequency |
Regulation of steady-state 0~5% Regulation of the transient ≤ ± 10% Stabilization time ≤ ± 10s Volatility ≤ ± 1% |
Weifang Hualing POWER CO. Ltd. It is located in the Power city, WEIFANG. With the integration of R&D, Design, Producing, Marketing and whole project construction, specializes in Energy, Electricity power, energy-saving, Environmental protection project.
The company has been identified OEM certificates by 8 World famous Engine group, ISO9001 quality management system certification, China energy-saving product certification. The company invested 2.6 billion RMB in the product line, and now is the first and top diesel engine and gas engine product line.
We produced a series multi-point injection electronic control engine and report to the National Development and reform commission, series of engines on the HL. CNG special report on current trends.
Since 2008, the product of HUALING Power Co., Ltd. Enter to the oil industry, develop and produce wellhead gas generating set, now has been widely used in the CBM oil brand and running in the subsidiaries.
