AMICO is the professional gas generator set manufactory, our main products are natural gas genset, biogas genset and the coalbed gas genset. The rated power range is from 30kW up to the 1200kW.
>> The brand new Research & Development platform for gas generator.
>> The fast dynamic response, similar to Diesel Engine
>> Higher power generation efficiency and good economy, more than 15% increase than normal products.
>> The use of lean-burn control technology, exhaust temperature is much lower, higher reliability.
>> Good emission, to meet the latest national emission standards.
>> High Automation, more convenient of one-button operation
>> Genset unit can adapt to much wider gas concentration, it can use the coalbed gas as low as 8%.
>> Genset unit adapt to much wider gas source of the user's requirements, can be adapted to 3KPa-20MPa pressure gas source.
>> Electronic control fault diagnosis, more convenient for maintenance.
>> Electronical controlled adaptive technology, it can automatically meet the changes of gas composition, pressure, temperature and humidity.
|
Natural Gas Generator 30-1200kW, Biogas Generator (30-1000kW), Coal gas generator set (30-1000kW) |
0.8PF, 50HZ, 3Phases 4Wires, 400V/230V, 1500 or 1800 r/min
(other voltage grades or single-phase alternators are available upon on customers’ requirement) |
|
Genset Model |
Power(kVA/kW) |
Speed
(RPM) |
Full Load
(m 3 /h) |
Engine Model |
Disp. (L) (Cylinder) |
Alternator Model |
Dimension
L× W× H(mm) |
Weight (kg) |
|
standby |
prime |
|
30GF-NG-AMD |
33/41.25 |
30/37.5 |
1500 |
9 |
NQ100N |
3.759 (4) |
FD1J1-4 |
1720*820*1250 |
780 |
|
50GF-NG-AMD |
55/68.75 |
50/62.5 |
1500 |
15 |
6B |
6.234 (6) |
EG225S-50N |
2170*900*1400 |
1000 |
|
60GF-NG-AMD |
66/82.5 |
60/75 |
1500 |
18 |
YC6105 |
6.494 (6) |
EG225S-60N |
2190*900*1400 |
1100 |
|
90GF-NG-AMD |
99/123.7 |
90/112.5 |
1500 |
27 |
6BT |
5.9 (6) |
EG225L-90N |
2240*1000*1400 |
1200 |
|
120GF-NG-AMD |
132/165 |
120/150 |
1500 |
36 |
6CT/ or WT615 |
8.3(6) |
EG225L-120N |
2700*1120*1600 |
1500 |
|
160GF-NG-AMD |
176/220 |
160/200 |
1500 |
48 |
WT615 |
9.726(6) |
EG280M-160N |
2900*1150*1680 |
1750 |
|
200GF-NG-AMD |
220/275 |
200/250 |
1500 |
60 |
T12 |
11.569(6) |
EG280L-200N |
3200*1150*1720 |
1950 |
|
250GF-NG-AMD |
275/343.7 |
250/312.5 |
1500 |
75 |
T12 |
11.569(6) |
EG280L-250N |
3250*1150*1720 |
2050 |
|
350GF-NG-AMD |
385/481 |
350/437.5 |
1500 |
105 |
K19 |
18.9(6) |
EG315M-350N |
3500*1700*2100 |
3000 |
|
500GF-NG-AMD |
550/687.5 |
500/625 |
1500 |
150 |
WD269 |
26.9(12) |
EG355L-500N |
3700*1700*2100 |
4500 |
|
700GF-NG-AMD |
770/962.5 |
700/875 |
1500 |
210 |
K38 |
37.8(12) |
EG400M-700N |
5560*1880*2350 |
8800 |
|
1000GF-NG-AMD |
1100/1375 |
1000/1250 |
1500 |
300 |
K50 or Q2160G |
50.3(16) |
EG400L-1000N |
5900*1780*2470 |
12500 |
|
1200GF-NG-AMD |
1320/1650 |
1200/1500 |
1500 |
360 |
TBG620V16 |
70.82(16) |
EG450S-1200N |
5900*1820*2470 |
13500 |
AMICO TECH CHENGDU Co., Ltd is a Gas Power Control Professor with Gas Engine R&D, Control system supports, technology training and Select Services. As well, AMICO is a Professional Manufactory for Gas Engine Power Units and Gas Generator Sets.
Gas Engine Units are independently developed products of AMICO. It is using Lean Burn Combustion technology; Assemble famous brands of gas engine and alternator, gas engine units to achieve the overall electronic control. The applicability of Gas Engine Units is Large. The Units can use Natural Gas (Including CNG and LNG), Liquefied Petroleum Gas (LPG), Associated Gas of Oilfield. Widely used in oil and gas fields, CNG inject Station, coal mine, refuse landfill, farms electricity power station and other civilian areas.
AMICO is located at Chengdu Modern Industrial Zone with 20000 square meters R & D and production base. 80% Employees of get the High Educations. The Senior Engineers, Doctors and Masters about 30 People. The main engineers of R&D team had to participate the in the drafting of Part of the Standard for the Gas Automobile. It commits to the 863 Project-Natural Gas Engine Development. AMICO has the Top Automatic Text System and equipments for the Gas Engine Units and Gas Generator Sets. The Company gets the IS09001: 2000 Quality System Certification and it is the SICHUAN High-Tech Enterprise.
AMICO adheres to the avail of customers first, sales and service system throughout China, Southeast Asia, MID East and other countries and regions almost dozens of station. We have establish the cooperation relationship with CNPC, Sinopec, PDVSA, SHELL etc. We hope provide to the new and old customers with more excellent products and perfect service.
