Quick Details
Place of Origin: Jiangsu, China (Mainland)
Type: Nickel Strip
Application: Chemical processing Pollution control Pulp and paper production Indus
Grade: Nickel Alloy N08800
Ni (Min): up to standard
Resistance (μΩ.m): up to standard
Powder Or Not: Not Powder
Ultimate Strength (≥ MPa): up to standard
Elongation (≥ %): up to standard
Model Number: Nickel Alloy
Brand Name: FLS, FLS
size: as your requirment
nate: we also provide other meterials
surface: 2B,2E
Packaging & Delivery
Packaging Details: | standard seaworthy export packing or based on customer's requirement |
---|
Delivery Detail: | 7-15 days after received your deposit. |
---|
Nickel Alloy N08800
Introduction
INCOLOY alloys belong to the category of super austenitic stainless steels. These alloys have nickel-chromium-iron as the base metals, with additives such as molybdenum, copper, nitrogen and silicon. These alloys are known for their excellent strength at elevated temperatures and good corrosion resistance in a variety of corrosive environments.
INCOLOY alloy 800 is an alloy of nickel, iron and chromium. The alloy is capable of remaining stable and maintaining its austenitic structure even after long time exposures to high temperatures. Other characteristics of the alloy are good strength, and high resistance to oxidizing, reducing and aqueous environments. The standard forms in which this alloy is available are round, flats, forging stock, tube, plate, sheet, wire and strip.
Chemical Composition
The chemical composition of INCOLOY alloy 800 is given in the following table.
Element | Content (%) |
---|
Iron, Fe | ≥39.5 |
Nickel, Ni | 30-35 |
Chromium, Cr | 19-23 |
Manganese, Mn | ≤1.5 |
Others | Remainder |
Physical Properties
The following table discusses the physical properties of INCOLOY alloy 800.
Properties | Metric | Imperial |
---|
Density | 7.94 gm/cm3 | 0.287 lb/in3 |
Mechanical Properties
The mechanical properties of INCOLOY alloy 800 are tabulated below.
Properties | Metric | Imperial |
---|
Tensile strength(annealed) | 600 MPa | 87 ksi |
Yield strength(annealed) | 275 MPa | 39.9 ksi |
Elongation at Break | 45% | 45% |
Other Designations
Some of the designations used to denote INCOLOY alloy 800 are listed below:
UNS N08800 | AMS 5766 | AMS 5871 | ASTM B163 | ASTM B366 |
ASTM B407 | ASTM B408 | ASTM B409 | ASTM B514 | ASTM B515 |
ASTM B564 | DIN 1.4876 |
|
|
|
Fabrication
Machinability
Machining characteristics of this INCOLOY alloy 800 are similar to that of iron-based alloys. This alloy tends to work-harden during machining.
Welding
INCOLOY alloy 800 can be welded by common welding techniques, using a matching filler metal.
Forming
This alloy exhibits good ductility and hence can be formed using conventional methods.
Hot working
INCOLOY alloy 800 can be hot worked at temperature ranges of 871-1232°C (1600-2250°F).
Cold Working
Cold working may be done on the alloy using standard tooling.
Annealing
INCOLOY alloy 800 may be annealed after cold working. Annealing should be done at 982°C (1800°F) for 15 min and then the alloy should be air cooled.
Applications
INCOLOY alloy 800 is used in the following applications:
Heat exchangers
Carburising equipment
Heating elements
Sheathing and nuclear steam generator tubing.
Stock
Form | Specification | Supply Form | Others |
Sheet | Thickness:0.40-4.75mm,General Width:1000,1219,1500mm | Whole Coil or piece of it | Cold Annealed,Surface 2B,2E |
Plate | Thickness:4.76-60mm,Width:1500,2000,2500mm,Length:3000,6000,8000,8500mm(Under 10mm plate can be coiled) | Whole Coil or piece of it | Single hot rolling,Solid solution annealed state,Surface 1D |
Belt | Thickness:0.10-3.0mm,Width:50-500mm | Whole Coil or Specified size | Cold Annealed,Surface 2B,2E |
Bar & Rod | Rolled barΦ5-45mm,Length≤1500mm | Polished Bar(circle,Square) | Solution annealing,descaling |
Forged barΦ26-245mm,Length≤4000mm |
Weld tube | Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm | Base on your requirement | Use for PHE |
Seamless Tube | Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm | Base on your requirement | Use for PHE |
Wire | Outer diameterΦ0.1-13mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Forged piece | roundness and square alloy | Base on your requirement | Steel, Alloy |
Flangs | All kinds of Flangs | Base on your requirement | Steel, Alloy |
Welding Material | Coil wire Φ0.90mm/1.2mm/1.6mm | Base on your requirement | Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France. |
Straight WireΦ1.2mm/1.6mm/2.4mm/3.2mm/4.0mm |
Welding rodΦ2.4mm/3.2mm/4.0mm |
Tube | Elbow, three links, four links, different diameter size | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Explosive bonded laminate | Raw Sheet Thickness≥2mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
After many years developments, Wuxi Fuller steel trade Co., Ltd. Has become one of the level-one suppliers of China Petrochemical. Now the company is mainly focusing on the import and export all kinds of alloys, such as Ni and Nickel based alloy, Ti and Ti alloy, Super austenitic stainless steel;
Our main products are Nickel & Nickel Alloy: RA300/RA 602 CA/Monel 400/Monel-K500/Inconel 600/601625/718 /INCOLOY 800/801/825; Stainless steel sheet/coil by ASTM, AISI, JIS, EN, GB standard, main material are 201, 202, 301, 304, 304L, 309S, 310S, 316, 316L, 317L, 321, 316Ti., 409L, 410, 410S, 416, 420, 420J1, 420J2, 430, 436, 439, 441, 444, 446 etc.; Seamless steel pipe, welded pipe, Spiral welded pipe; Tin Coil, Silicon Steel, Tool Steel, Galvanized sheet, PPGI etc.
Understanding our customers, we care about the future of our business. Up to today, with reasonable price and good quality, all our products sell well in the international marketing. We want to ensure that you get our good service, only high quality and speedy delivery. We sincerely want to supply you with high quality products and perfect service based on our efficient management and professional work teams. Because professional, so trust!
