According to user needs (electricity, location, number of days subsistence, load type, etc. ) for system design.
System Device Configuration |
name |
Specification |
unit |
quantity |
notes |
Solar panel |
160W |
PCS |
2 |
Mono silicon |
Component support |
320W-4*4 |
a |
1 |
Hot galvanized angle, folding |
Battery |
2V120Ah |
a |
12 |
PV-specific lead-acid batteries |
PV Controller |
24V10A |
a |
1 |
|
Inverter |
24V300W |
a |
1 |
Sine wave, efficiency> 85% |
Power Distribution
Unit |
24V/220-300 |
a |
1 |
Lightning protection, anti-anti, convergence, AC and DC power distribution |
System performance |
1. System peak sunshine hours average reference value: 4 hours;
2. Average daily generation capacity of PV modules: 1KWh;
3. Battery capacity can provide electricity for 5 consecutive rainy days;
4. Continuous load capacity of the system 300W, maximum load capacity of 320W;
5. For TV and other inductive load at startup, where there is power failure protection, you can restart the inverter;
6. Extreme weather conditions, may be appropriate to reduce the use of electrical appliances working hours; |
Electrical and power reference |
name |
specification |
quantity |
Total power |
time |
Power consumption |
Energy saving lamp |
10W |
2 |
20W |
4h |
80Wh |
21 ' TV |
75W |
1 |
75W |
4h |
300 Wh |
Satellite receiver / DVD |
25W |
1 |
25W |
4h |
100 Wh |
Radio |
|
1 |
|
|
Can be ignored |
total |
|
|
120W |
|
480Wh |
Located in Huishan Industrial Park of Wuxi city, Wuxi MY Solar Technology Co., Ltd is a new high-tech enterprise specializing in the solar photovoltaic system R & D, manufacturing and marketing.Our main products include monocrystalline and polycrystalline solar panels with output from 3W to 300W, off and combined to the grid solar power supply systems with output range from 50W to 10KW.Being strictly manufactured according to TUV & CE standards, our items are widely used in residential, commercial, industrial and other solar systems.with professional design, good product quality and considerate service, MY solar will make you satisfied.
