Generator set:
Frequency (Hz) 50/60
Rated output (kVA) 1.8/2.0
Max output (kVA) 2.0/2.2
Rated AC Voltage (V) 230/120/240
Power Factor 1.0
DC output 12V/8.3A
Phase Single Phase
Alternator Type Self-excited, 2-pole brush AVR
Starting System Electric
Noise Level (Dba/7m) 68-72Dba
Fuel Tank Capacity (L) 16L
Continues Running Time (hr) 7hr
Engine:
Engine Model: HF186FA
Engine Type: Single-cylinder, vertical, 4-stroke air-cooled diesel engine
Max output of engine: 9.0HP/3600rpm
Bore × Stroke (mm) 86× 72
Displacement Capacity(CC) 418CC
Fuel Consumption rate(g/kw. H) less than 280
Fuel 0# or -10# light diesel oil
Lubrication Oil Volume (L) 1.65L
Combustion System Direct Injection
Welder:
No-load Voltage 65-70V
Rated Welding Voltage 28-32V
Max Welding Current 190A
Welding load continuous ratio 50%
Current Accommodate 80-190A
Welding Rod 2.5-4.0mm
