Working principle
This kind of processor is designed based on the mechanism of water of different quality to be treated by different electromagnetic fields. The main engine generates electromagnetic field for water treatment. Under the condition of resonance, having been deeply broken, associative key of water in large association structure is dissociated into unimolecular with strong activity or water molecules in small association structure. As a result, the physical structure and properties of water are changed, specifically in stronger polarity of water molecules, larger dipole moment, and greater ability to hydrate components such as calcium and magnesium and carbanion that are easy to form scale, as well as to prevent scale formation. Meanwhile, under the condition of high-frequency electromagnetic field, original scale crystallization gradually becomes soft, falling off and dissolved, thus the purpose of scale removal is obtained.
Product features:
1, Low investment, low running cost, limited electricity required
2, Small volume, less space occupation, convenient installation
3, No noise, no smell, no need to be added to any chemical composition
4, Maintenance free for designed service life of fifteen years
5, Free operator, full automatic operation
6, Solid silicon in circuit design, stable and reliable working
7, Scale prevention and removing, sterilization and algae killing, anti rust and corrosion, activate water quality
Technical parameters:
| Model | Inlet and outlet | horizontal type(Look picture) | output power
(W) | flow rate
(t/h) |
| (in) | (mm) | A | B | C | D | Weight(kg) |
| YL-0.5 | 0.5 | 15 | 600 | 159 | 360 | 120 | 35 | 25 | 1.8 |
| YL-1 | 1 | 25 | 600 | 159 | 360 | 120 | 35 | 25 | 4.9 |
| YL-1.5 | 1.5 | 40 | 600 | 159 | 360 | 120 | 35 | 25 | 12 |
| YL-2 | 2 | 50 | 600 | 159 | 360 | 120 | 35 | 25 | 19 |
| YL-2.5 | 2.5 | 65 | 600 | 159 | 360 | 120 | 40 | 25 | 28 |
| YL-3 | 3 | 80 | 700 | 219 | 460 | 120 | 45 | 50 | 50 |
| YL-4 | 4 | 100 | 700 | 219 | 460 | 120 | 50 | 50 | 80 |
| YL-5 | 5 | 125 | 700 | 219 | 460 | 120 | 55 | 70 | 125 |
| YL-6 | 6 | 150 | 750 | 273 | 510 | 120 | 65 | 70 | 180 |
| YL-8 | 8 | 200 | 800 | 325 | 560 | 120 | 80 | 80 | 320 |
| YL-10 | 10 | 250 | 850 | 377 | 610 | 120 | 90 | 120 | 490 |
| YL-12 | 12 | 300 | 900 | 426 | 660 | 120 | 120 | 210 | 710 |
| YL-14 | 14 | 350 | 950 | 478 | 710 | 120 | 130 | 250 | 1000 |
| YL-16 | 16 | 400 | 1000 | 530 | 760 | 120 | 150 | 330 | 1400 |
| YL-18 | 18 | 450 | 1050 | 620 | 810 | 120 | 180 | 410 | 1600 |
| YL-20 | 20 | 500 | 1150 | 720 | 910 | 120 | 200 | 500 | 1970 |
| YL-24 | 24 | 600 | 1250 | 750 | 1010 | 120 | 260 | 660 | 2850 |
| YL-28 | 28 | 700 | 1350 | 820 | 1110 | 120 | 320 | 900 | 3880 |
Jiangsu YLD Water Processing Equipment Co., Ltd. is a high-tech enterprise, specialized in the research, development, design, manufacture, installation, technical consultation and personnel training.
We mainly produce electronic scale removal, UV sterilization, filtration, softening and cyclone grit removal technology and equipment. With strong technical force and rich experience, our company strictly implements ISO9001 system in the plan and management. "High technology leads to market development" is our basic concept.
We have extensively cooperated with domestic key universities, research institutions and foreign professional manufacturers, such as DOW (Dow) Chemical Co., Ltd., HYDRANAUTICS (Hydranautics) Company, Company (a professional manufacturer of multi-stage pumps), MILTONROY (Milton) Corporation (a metering pump manufacturer), the US Soft Controller KINETICO and OSMONICS, We have also fully introduced advanced technology. Thus, our technology is always in the leading domestic level. Over the years, our company has specialized in a variety of water treatment equipment for food, beverage, pharmaceutical, hospital, precision electronic, fine chemical, electricity, painting and surface cleaning industries.
Our "LYD" high-quality products at reasonable prices and perfect after-sales services have won great trust from worldwide customers,
We are willing to cooperate with the friends from all over the world and creat fine future together!
