Principle of operation
This product is researching and developing based on the advantages of heat regeneration and non heat regeneration, the gas regenerated makes the desiccant regenerate after raising temperature, thus, it can not only improve the effect of regeneration, but decrease the quantity of regenerated consume gas.
Technical characteristics
1. Heating control use non-contact solid-state switch, with automatic constant temperature control, and it has long service life, owning kinds of breakdown warning systems.
2. Advanced variable program, it runs steady and reliable.
3. Choose microcomputer control, and the digital shows two towers work in turn.
4. Choose the microcomputer control components, making sure that the output signal arrives at instructions save and accurately.
5. Ensure the product of gas has stable and reliably dew point, also, it can save energy consumption.
6. It has concise and easy structure, humanized design, further more, it is convenient to operate and maintain.
7. When the parts of eupyrexia appear stoppage, it can switch for pyrexia operation mode automatically.
8. Equipped RS485/RS232 and combined transport interface, so it can go on remote communicating, centralized monitoring and air compressor connected controlling.
|
Model |
Rated amount of gas processing |
Inlet and outlet caliber |
power |
weight |
|
(Nm3/min) |
DN (mm) |
|
KHD_3/8 |
3 |
32 |
220/50,1.35w |
370 |
|
KHD_6/8 |
6 |
40 |
220/50,3.1w |
665 |
|
KHD_12/8 |
12 |
50 |
380/50,5.8w |
1090 |
|
KHD_20/8 |
20 |
65 |
380/50,9.7w |
1660 |
|
KHD_30/8 |
30 |
80 |
380/50,14.7w |
1890 |
|
KHD_40/8 |
40 |
100 |
380/50,19.5w |
2580 |
|
KHD_60/8 |
60 |
125 |
380/50,29.7w |
3750 |
|
KHD_80/8 |
80 |
150 |
3800/50,41.5w |
4130 |
|
KHD_100/8 |
100 |
150 |
380/50,52w |
4760 |
|
KHD_150/8 |
150 |
200 |
380/50,76.5w |
5860 |
|
KHD_200/8 |
200 |
200 |
380/50,93w |
7280 |
