Specifications
1. PSA Technology
2. Adjustable flowrate
3. Large LCD display
4. Nebulizer, purity indicator, pulse oximeter, high temp alarm
5. Oxygen concentrator with two bottle:
6. Flow rate: 0-8L/min
7. Purity: 93± 3%
8. Outlet Pressure (Mpa): 0.04-0.07
9. Sound Level: ≤ 50db
10. Power : AC220V± 10%, 50/60± 1Hz; AC110V± 10%, 50/60± 1Hz
11. Power Consumption: ≤ 480W
12. Timer:Present Working Time, Accumulating Time, Presetting Time from 10mins to 40hours
13. Alarm: Power failure alarm, High&Low pressure alarm
14. Net Weight: 25Kgs
15. Size (mm): 365× 375× 600mm
ALTERNATIVELY
1. Nebulizer
2. Low purity alarm: When oxygen purity is above 82%, it will give green light; When the purity is blow 82%( 82% not included), it will give red light
3. Maintenance alarm: Alarm for maintenance after 3000 hours operation
4. Alarm for high temperature inside systems above 50° C
5. Pulse oximeter: Fingertip pulse oximeter is available for monitoring patient oxygen saturation on site.
6. Small LCD display: Accumulating time; Present working time presetting time. *Dual Flows
Rated power (VA) | 550W |
| Operation voltage (V/Hz) | AC230V (± 10%)/50Hz (±1Hz) |
| Oxygen flow (L/min) | 0-10 |
| Oxygen concentration | 93% (± 3%) |
| Outlet pressure (Mpa) | 0.04-0.07 |
| Alarm | Power failure; low/high pressure; temperature (optional); low concentration (optional); maintenance reminding after 3000 hours' operation (optional) |
| Noise level (dB) | ≤ 55 |
| LCD display | Accumulated time; present time |
| Large LCD display (optional) | Pressure indication (accuracy: 0.001MPa); |
| Accumulated working time (range: 0-10000hours); |
| Present working time (accuracy:1 minute); |
| Preset time (accuracy: 1 minute) |
| Optional: temperature indication (accuracy: 0.1); |
| Oxygen concentration indication |
| Maintenance reminding |
| Electrical safety classification | Class II Type B |
| Product category | Class II a |
| Net Weight (kg) | 3060 |
| Dimension (mm) | 380×380×560 |
| Low concentration alarm (Optional) | When oxygen concentration is 85% or above, the green lamp is on; when oxygen concentration isbelow 85%, the red lamp is on, indicating low concentration. |
| Fuse | F7A/250V |
