Specification:
Rate output power(kw): 155(130kw-180kw choosable)
Max out put power(kw): 160
Rate frequency(Hz): 50 (50/60 adjustable)
Phase: Three phase
Cylinder arrangement: In-line engine
Number of cylinders: 6
Voltage range(v): 230/400(adjustable)
Engine brand: Cummins
Fuel consumption(L): 35.4
Size(mm): 2500*850*1650
Weight(kg): 1670
Feature:
Low fuel consumption
High availability and reliability
Outstanding load acceptance
Long maintenance intervals
Control panel:
1. Display water temperature.
2. Display oil pressure
3. Display oil pressure
4. Display battery charging current.
5. Display generating set operating time.
6. Electrical start button.
7. Base fuel tank is included in the price.
Standard Equipment:
1. Equipment conforms to CE and OQS - ISO9001-2000 quality system standards.
2. Unit power, voltage, engine brand and alternator brand can be adjusted.
3. Units were tested under the standard conditions of temperature and atmospheric pressure, each not less than three hours.
4. Fuel consumption parameters based on the original engine parameters and actual test.
5. The KVA units of power units is 0.8 to calculate the power factor.
6. Converter generator is Brushless excitation, the class of insulation is F.
Warranty
The standard warranty period is 1 year or 1500 running hours since the delivery date, depends on whichever comes first.
Packing
All the parts are packed in export wooded cases.
Shijiazhuang Gongyi Mechanical & Electrical Co., Ltd is devoted to long-term development of generator set as well as the development, production, sales, maintenance and service of high-quality generator sets for power generation and special uses with power range of 30KW to 3600KW. Its products extend all over the country and all walks of life. The company has been certified to ISO9001: 2000 Quality Management System, with strong advantages in energy conservation, noise reduction, price, sales service and delivery time. Dawn generator sets mainly use engines of Cummins, Doosan (Daewoo), Volvo, MTU, Wandi, Jichai, Tongchai, Shangchai, Weichai and other world-renowned brands.
To meet requirements of different users, our company also offers automatic switch over three remote monitoring and automatic parallel operation systems, low noise, container and different voltage special sets, constant voltage and current water supply diesel pump units, drilling rigs and firefighting units. In recent years, our company has stridden forward the fields of wind power, hydropower, methane and natural gas power generation. Our company has advanced test equipment, reliable product quality and sound service network, manages in strict accordance with the international quality system, and is favored by users.
