Rated Power: 3000W Wind wheel diameter: 3.60M/3.53M
Weight: 419KG
Blade Material: Aluminum Alloy
The number of blade: 3
Minimum wind speed start: 1.5m/s
Minimum power wind speed: 2.5m/s
Minimum charge wind speed: 3.5m/s
Rated wind speed: 13m/s
Maximum cut off wind speed: 15m/s
Resistant to wind speed limit: 60m/s
The type of Generator: Three-phase AC maglev wind turbine
Controller outputvoltage: DC48
Controller output current: ≤ 130AMP
Controller brake system: Over speed automatic Three-phase short-circuit braking Normal operating temperature: -40~50 º C
| Weight: | 419 Kg |
| Blades: |
| Number of Blades: | 3 |
| Rotor Height/Diameter: | 3.53m/3.60m |
| Blade Material: | Anodized Aluminum Alloy |
| Operate Mode |
| Start-up Wind Speed: | 1.5m/s |
| Cut-in Wind Speed: | 3.5m/s |
| Cut-out Wind Speed: | 15m/s |
| Survival Wind Speed: | 60m/s |
| Safety Mechanism |
| Over Speed Braking: | Yes. (Setup by Power Controller) |
| Manual Brake: | 3-phase short-circuit Switch |
| Generator |
| Type: | AC, Direct Drive, Weather Sealed, 3 Phase Synchronism PMG. |
| Rated Output: | 3000W |
| Mounting |
| Foundation Mounting: | Min. Height above ground: 3m |
| Roof Mounting: | Min. Height above Roof: 2m |
| Bedplate Mounting: | Used where deep excavation cannot be applied |
| Warranty |
| Limited Warranty: | Two years on components |
Xinda Green Energy Co., Limited is specialized in handling the business of vertical and horizontal wind turbine generator, various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, both vertical and horizontal, small hydro turbine system(low head and higher head), wind solar hybrid system, high efficiency high seepd permanent magnet motor, street lamp and so on
Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.
