Fuel type LPG single-use NG single-use
NG & LPG two-use
Description
Generator Specification: Single phase
Frequency (Hz) 50 60 50 60
Running Power (KW) 2.5 2.6 2.4 2.5
Peak power (KW) 2.8 2.8 2.6 2.8
DC Voltage (V) / Current (A) 12V/ 8.3A
Generator Type Single Phase AC Synchronization with Brush
Engine Specification
Engine Model Number CC170F-LPG CC170F-NG-II
CC170F-NG/LPG
Engine Type Single Cylinder, 4-Stroke, OHV, Forced Air-cooled
Bore × Stroke (mm) 70× 54
Displacement (CC) 208
Starting Method Recoil start /Electric start
Ignition System Transistorized Coil Ignition (T. C. I. )
Engine Oil Capacity (L) 0.55
Min. Fuel Consumption LPG: About 0.35kg/kW@h NG: About 0.40m3/kW@h
Shanghai Chenchang Power Technology Co., Ltd., is a high-tech enterprise specialized in developing & manufacturing natural gas, LPG and biogas engines, generators, water pumps and other power equipments.
