Lovol Generator Set

Lovol generator set
Power from 25KW to 108KW
Engine: Lovol
Alternator: Stamford or thers
Certificate: CE and ISO
Lovol Generator set

Detailed Product Description:

Technical Specifications and of lovol Diesel Generator Set:
Techinical data
Genset model: GLW
Genset output Power range: 23KW~108KW
Rated Voltage: 50Hz: 400/230V 60Hz: 480/277V
Three-phase voltage available: 480/277V 440/254V 416/240V 220/127V 207/120V
Frequency: 50/60Hz
Power Factor(COS): 0.8
Rated Speed: 1500/1800RPM
Output Type: AC Three Phase/Single Phase
Inspiration Method: Natural aspirated or Turbocharged

Diesel Engine
Brand: Levol(Chinese)
Model: /
Engine Structure: 3L-6L
Cooling Method: Water cooled
Rotating Speed: 1500/1800RPM
Governor System: Electrical or Mechanical Governor
Aspiration mode Natural aspirated or Turbocharged
Starting method: 12/24V DC electric starting
Displacement(L): /
Bore× Stroke(mm): /
Compression Ratio: /
100%load fuel consumption(L/h): /

Alternator
Brand: Leroy semor, Stamford, Meccalte, Maraton etc.
Model: /
Excite Type: Brushless, AVR automatic voltage regulating
Connecting Type: 3 phase and 4 wires/single phase
Steady Frequency Change: 0~5%
No load voltage: ≥ 95%~105
Steady voltage: ≤ ± 1
Insulation degree: H degree
Exclosure degree: IP 23

The components of the genset
(1)Diesel engine; (2)Generator; (3)Control panel

The Accessories
Wave pipe, curved pipe, muffler, accumulator and the connecting line, shock-absorbing spacer, and data.

Control panel
The control panel is GZ6110 control panel, one controller, a key power switch, a DC power indicator, Emergency button.
According to customers requirment, can provide ammeter, voltmeter, frequency tables, etc,
Built-in the fine-tuning knob of speed and voltage.
Can be configured according to customer requirements or pre-warm the engine oil button.
