Justpower Series Double Bearing Bruthless Alternator

Justpower Series Double Bearing Bruthless Alternator
Price: US $ 500/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T

Quick Details

Place of Origin:

Fujian, China (Mainland)

Brand Name:

Stamford Brushless Alternator

Model Number:

Stamford Brushless Alternator

Output Type:

AC Three Phase, A.C. synchronous alternator

Speed:

1500RPM / 1800RPM

Frequency:

50HZ/60HZ

Rated Power:

6.5kw to 536kw

Rated Voltage:

400V / 440V

Phase No::

three-phase

Brushless:

Brushless

Color:

White / creamy white / Green / Black / Blue / Red



Packaging & Delivery

Packaging Details:
EXPORT STANDARD PACKING
Delivery Detail:18 days to 25days

Specifications
H CLASS, IP 23, BRUSHLESS, WITH AVR,100% COPPER
Detailed description
1.Brushless synchronous alternator
2.Output:6.5kw-1150kw single-phase and three-phase
3.Convenient installation and maintenance
4.Frequency: 50Hz 60Hz  1500 1800RPM
5.Characters: 4-pole, brushless, H class insulation, IP21
Technical Data
MODELPOWER(1500RPM/50HZ)400VPOWER(1800RPM/60HZ)440VDIMENSION (CM)
KWKVAKWKVA
JPA164A6.58.18.210.358*56*62
JPA164B8.8111113.858*56*62
JPA164C10.813.513.516.958*56*62
JPA164D12.816162058*56*62
JPA184E1822.52328.872*56*62
JPA184F2227.527.534.472*56*62
JPA184G2531.33037.572*56*62
JPA184H3037.537.546.972*56*62
JPA184J3240405072*56*62
JPA224C3442.54252.584*58*90
JPA224D40505062.584*58*90
JPA224E4860567093*58*90
JPA224F5872.57087.593*58*90
JPA224G68857897.597*58*90
JPA274C8010094117.594*69*97
JPA274D91113.8110137.594*69*97
JPA274E112140134167.594*69*97
JPA274F128160152190106*69*97
JPA274G144180174.8218.5111*69*97
JPA274H160200196245116*69*97
JPA274J184230224.8281116*69*97
JPA274K200250239.2299116*69*97
JPA314C200250235294133*79*106
JPA314D236295280350133*79*106
JPA314E260325315394133*79*106
JPA314F304380365456.3133*79*106
JPA354C360450440550149*87*116
JPA354D400500475594149*87*116
JPA354E480600570712.5149*87*116
JPA354F536670620775149*87*116



MECHANICAL FEATURES

Voltage regulation

Voltage regulation refers to the change of voltage from no-load to full-load with power factor ranging from 0.5 to 1 and 2.8%s fluctuation of the speed of engine. Voltage is adjusted via potentiometer of AVR, model: SX460, SX440

Axis and Key

All of alternator rotors should pass balance test, whose vibrations are lower than the minimum of BS6861 P.1,G 2.5 two bearing alternator has a half-key testing balance

Terminal and terminal box

The three-field alternator had 12 leads brought out to the terminals in the terminal box. The terminals are put on the non drive end . The box is equipped with removable panels.


ELECTRIC FEATURES

INSULATION

Insulation Class H

All regulatory components are made up with special materials and are immersed in lacquer by peculiar tech. Vanish and colophony materials are develop to strengthen the processing and machinery intensity of winding and revolving parts for protecting the alternator work under corrosive environment.

Winding and electric features

2/3 pith winding design can effectively eliminate the third harmonic wave(3th.9th,15th) of the voltage ,which is the best design of UPS for nonlinear load .Connected with the network in parallel, the structure can restrain excessive currents in the midline. This and the 2/3 pitch help to check the wave distortion and output voltage.

Phone interference and Radio interference

THF (defined by 40thpart of BS4999) <2%.TIF<50
Brushless apparatus and quality AVR ensure little radio interference in transmission. RFI noise filter is also available.

Manufacturing Standard

GB755,BS 5000,VDE 0530, NEMA MG1-22,IEC34

Warranty policy

JUSTPOWER product has guarantee for one year or 1200 hours whichever reach first from ex-factory date. During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance of alternator.


Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Warranty: 1 Year
Wire: 100% Copper
Frequency: 50/60Hz
Output Power: 50-1000kw
Phase: 3
Color: Multi-Colors
JustPower is a professional supplier of power generation products, including 5-2000kVA super silent/silent/open diesel generator sets and synchronous alternators with 5 years' experience. We have a group of experienced production, after-sales, technical & sales people, aiming at providing the best power supply solutions for partners worldwide. We are OEM partners for Perkins, Cummins, Deutz, Doosan, Isuzu, Mecc alte & Stamford.
