Specification
Model |
| MY-IG600 | MY-IG1000 | MY-IG2000 | MY-IG2600 | MY-IG3600 | MY-IG6500 |
| Rated power output(KW) | 0.45 | 0.9 | 2 | 2.6 | 3 | 5 |
| Max. power output(KW) | 0.5 | 1 | 2.2 | 2.8 | 3.1 | 5.5 |
| Engine | Type | Forced Air-Cooled, 1-Cylinder, 4-Stroke, OHV |
| Displacement | 31cc | 53cc | 125cc | 149cc | 270cc | 389cc |
| Rated power output | 0.65KW/5500RPM | 1.2KW/5500RPM | 3.2KW/5000RPM | 3.7/5000RPM | 5.6/3600RPM | 7.5/3600RPM |
| Max power output | 0.7KW/5500RPM | 1.4KW/5500RPM | 3.5KW/5000RPM | 3.9/5000RPM | 6.2/4200RPM | 8.0/3600RPM |
| Bore*Stroke(mm) | 39X26mm | 43.5X35.8mm | 52.4*57.8mm | 57.4×57.8mm | 77×58mm | 88×64mm |
| Ignition system | T.D.I | T.D.I | T.D.I | T.D.I | T.D.I | T.D.I |
| Starting system | Recoil Starter | Recoil Starter | Recoil starting/Electric/Remote | Recoil starting/Electric/Remote | Recoil starting/Electric/Remote | Recoil starting/Electric/Remote |
| Recommend Fuel | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline |
| Fuel tank capacity | 1.5L | 2.7L | 7.0L | 7.0L | 13L | 20L |
| Fuel consumption | 480g/kw.h | 420g/Kw/h | 400g/Kw/h | 367g/Kw/h | 450g/kw h | 360g/kw h |
| Continous operating hour | 3.5 | 6 | 6.5 | 6 | 7 | 8.5 |
| Noise (7m away) | 58(7m) | 58dba | 65dba | 58dba | 59dba | 66dba |
| Generator | Rated output frequency | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ |
| Rated output voltage | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v |
| D. C. Output | 12V 2.5A | 12V 5A | 12V 8.3A | 12V 8.3A | 12V 8.3A | 12V 8.3A |
| A.C. Output | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v | 100v/110v/120v/220v/230v/240v |
| How Many Output | 1 | 1 | 1 | 1 | 1 | 1 |
| Standard Features | Large-capacity air cleaner | N | N | N | N | N | N |
| Fuel indicator | Y | Y | Y | Y | Y | Y |
| Voltmeter | N | N | N | N | N | N |
| Auto voltage adjustor | Y | Y | Y | Y | Y | Y |
| Oil alert system | Y | Y | Y | Y | Y | Y |
| Circuit breaker without fuse | Y | Y | Y | Y | Y | Y |
| Circuit protector | Y | Y | Y | Y | Y | Y |
| Options | Parallel connection box | Y | Y | Y | Y | N | N |
| Digital display control panel | N | Y | Y | Y | N | N |
Product Description
IG Series inverter technology
takes the raw power produced
by the generator and passes it
through a special electronic
microprocessor to provide clean
and stable power, safe for computers
and other sensitive electronic
devices.
