HYE wind permanent magnet generator power system on-grid home

Wind power grid-tie system A is is a semi-autonomous electrical generation or grid energy storage system which links to the mains to feed excess capacity generated by wind turbine back to the local main electrical grid. When insufficient electricity is generated electricity drawn from the mains grid can make up the shortfall.
Residences and businesses that have a wind power grid-tie system permitted in many countries to sell their energy to the utility grid. Electricity delivered to the grid can be compensated in either net metering or feed-in-tariff, HYE wind power grid-tie system offers complete system solutions for both compensation ways.
HYGCI series wind power grid-tie inverter is the core part of the whole system, the inverter is developed specially for HY series wind turbine according to HY series wind turbine special features with an optimized power curve pre-written into inverter and smart over-voltage braking protection, which offers a reliable combination of high efficiency, easy-installation, high wind protection and grid-failure protection.

Special Features
Integrated Controller easy for installation
Integrated Isolation Transformer extra safety protection
Wider Input Voltage Range harvesting more power from breeze to gale
Programmable 20 Points of Power Curves optimize power harvest from wind
Optional Remote Monitoring system Monitoring remotely your installation
High Conversion Efficiency up to 95%
Certified with DIN VED 0126-1-1 Grid Standard
5 Years Warranty

System Protections
High Wind Protection software controlled braking system provides high wind protection with 3 minutes, 10 minutes and 30 minutes time-lapse braking modes. It's a consideration of system safety under the worst wind condition in natural environment.
Galvanic Isolation Protection HYGCI-15CL is constructed and designed to assure
Maximum safety during installation and operation. The maximum possible degree of safety is being assured by galvanic isolation of input and output; In case of any grid AC power failure, the grid feed-in will be shut down automatically according to the country-specific standard (e. G. DIN VDE 0126-1-1)

Standard System Solutions
 System Detail HY-W10GTS  HY-W15GTS  HY-W30GTS
 Rated AC output 1000W 1500W  3000W
 Wind Turbine HY-1000L , 110V  HY-1500L, 120V  HY-3000L,220V
Grid-tied Inverter 190V~260V, 50~60Hz 190V~260V, 50~60Hz 190V~260V, 50~60Hz
 Tower 3 m wall-attached tower  3 m wall-attached tower 11m  free standing tower
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Start Up(M/S): 2.3
Rated Wind Speed(M/S): 12
Over-Speed Protection: Blade Aerodynamic and Electromagnetic Braking
Over-Loader Protection: Electromagnetic Braking
Blade Material: Reinforced Nylon Glass-Fiber
Generator Type: Brushless 3-Phase Pma with High Performance Neodym
Certificates: CE , Isd9001, RoHS ,ETL
Controller Type: PWM or with Low Voltgae Charging Function
Product Life: 15 Years
Warranty: 3 Years
Rotating Shaft: Horizontal
Stress Way Of Blade: Resistance
Number Of Blade: 5 Blades
Guangzhou HY Energy Technology Limited Corp. Is a high-tech enterprise engaged in designing, manufacturing, marketing on highly reliable small wind turbines and serving in wind-solar hybrid power system integration technique.

Guangzhou HY Energy Technology Limited Corp.   Has made tremendous contributions to improve national wind generator manufacturing level under the breakthrough technique on wind turbine design conception and production craft since 2001, meanwhile, our breakthrough technique on wind-solar hybrid power system has also LED a large scale application in real circumstance.

HY Energy was appointed to be the drafter of off grid wind solar generating safety requirement standard No. (20074719-T-604) based on the advance technology inaugurator of perfect matching design on wind blade and generator and the perfect matching on wind energy and solar energy.

Guangzhou HY Energy Technology Limited Corp.   Is the sole enterprise passing design and manufacture of high reliable small wind turbine project and accepted by The Ministry of Science and Technology of the People' S Republic of China.

HY Energy' S wind turbine series has successfully been selected into WWEA 2010 and WWEA 2011 global high quality small or medium generator catalogue.
