Home Generator Products Hortizontal Axis Wind Turbine(Generator) 2KW/400RPM

Hortizontal Axis Wind Turbine(Generator) 2KW/400RPM

Hortizontal Axis Wind Turbine(Generator) 2KW/400RPM
Price: Negotiable/Piece
Min Order: 1 /Piece
QM Hortizontal Axis Wind Turbine(Generator) 2KW on/off grid system

QM-HAWT-2.0KW/400RPM(2KW Hortizontal Axis Wind is with high quality competitive prices and very mature design.

QM has advanced equipments(ABB TEST equipment for wind turbine generator) and manufacture process, completed quality management system(Samsung proven) and excellent technical team(Experts on Vertical Axis Wind Turbine/Generator/Blades/Electronic System) to provide high quality and environmental protection products and improved power supply solution and first-class after service for customers. We can supply long time warranty than other suppliers.

The wind generator are all made of NdFeB that We produces from 1996. The specific outer rotor magnetic circuit is designed in a way that the products have high generating efficiency, light weight, low starting torque, appealing appearance, easy installation and higher electric performance and use performance than the kindred products.
Horizontal Axis Wind Turbine(1-50KW) have special design; Controller/Inverter system is credible and professional, most of all, our WTG(Wind turbine generator) is quite special. (Directly drive, aslo We can supply wind turbine with gearbox)

If customers are interesting on our products, please do not hesitate to contact me, I will give you a competitive quotation ASAP.
QM-HAWT-2.0KW/400RPM TECHNICAL PARAMETER
Battery price  (USD) 529
Rotor  diameter (m) 4
Rated Rotated speed(r/m) 400
Rated wind  speed (m/s) 8
Rated power(w) 2000
Max power(w) 3000
Output voltage(v) 96
Start up wind speed(m/s) 3
Operating wind speed(m/s) 3-25
Security wind speed(m/s) 40
Height of tower (m) 6
Weight of top section (kg) 95
controller Parameter 96V 60A
Inverter Parameter DC96V→ user' s local voltage & frequency
tower pole type(mm) D89*4
20container(sets) 48
40container(sets) 96
Capacity and quantity of battery(reference) 8pcs12V100AH (for off grid system)
can supply power for Ice box, washer, waterpump, tv, lighting, electric fan, charger
Prod Model: QM-HAWT-2.0KW/400RPM
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Number Of Blade: Three Blade
Rotating Shaft: Horizontal
QM has recruited a technical team and all of team members are Professor-grade Engineers on Permanent Magnet Generator(Alternator) field. After rising the found as much as one hundred million RMB, QM has been building a new Axial Flux Permanent Magnet Generator(Alternator) factory for magnets, Permanent Magnet Generator(Alternator), Axial Flux Permanent Magnet Generator(Alternator) and Vertical Axis Wind Generator with exceed 400 employees.

The magnets of all our Permanent Magnet Generator(Alternator) are made of NdFeB which produced by us from 1996. The specific rotor and stator of our permanent magnet generator(alternator) for wind power and hydraulic power systems are designed in a way which is high generating efficiency as high as exceed 85%(Axial Flux Permanent Magnet Generator(Alternator)), light weight as light as 5.8kg for 0.1kW Axial Flux Permanent Magnet Generator(Alternator) and low starting torque as low as 0.1NM, appealing appearance, easy installation and higher electric performance and use performance than the kind of other products(RFPMG).

Under the tenet "Credit, Respect, Excellence and Share" and marketing belief "Quality is the basis of existence Basis, a Science & technology are the road of development", QM is devoted to development of wind energy and building international relationship with customers who intent to develop green and renewable power.

Exepet Permanent Magnet Generator(Alternator) and magnets production. Our direct drive Vertical Axis Wind Turbine(1-5KW VAWT), are all 50RPM direct drive, Horizontal Axis Wind Turbine(1-50KW) have special design; Controller/Inverter system is credible and professional, most of all, our Wind turbine generator is quite special(Direct drive), also we can supply wind turbine with gearbox)

All of QM's products are tested strictly before shipment with the most advanced equipment in order to make sure the quality of our products and our brand 'QM' for permanent magnets generator(alternator).

QM has UL1741, AS4777, CE, G83, RoHS, ISO14001, ISO9001 certificates, specialized in green and renewable energy industry with bright prospect, We would like to cooperate with the friends from all over the world and give green brightness to every friend who cares about environmental protection type new energy. Every friend from all circles to QM would be welcomed for visit, instruction and business negotiation.

Thank you for using QM Permanent Magnetic Products
