Home wind turbine
Wind turbine Feature:
1. Rare earth permanent-magnet generator
2. Small vibration and tiny friction, stable rotation in higher speed
3. Streamlined wind turbine body and blade outline design
4. Blades have 2 kinds, 300W-1kw have 3 PCS or 5 PCS choose, up to 2kw have lighted blades choose.
5. Noice level below 55dBaround the wind turbine tower
6. State of the art, workmanship and beautiful appearance
7. Use magnetic saturation technology, with 20years designed life;
8. Select high quality bearing, free to maintenance;
9. Anti-twist device, generator can whirl in each direction
10. Anti strong wind, the blade protect itself automatically,
11. Supply matched controller/inverter, make the system more stable.
Off grid wind power supply systems-FD2000 |
System
Basic Information |
Wind generator power: 2000W
Annual average energy: 5000kWh
Supply power for air-condition, refrigerator, water pump, washer |
|
Wind generator
|
Model |
FD-2000 |
Rated power |
2000W |
Starting wind speed |
3m/s |
Cut-in wind speed |
3.5m/s |
Rated wind speed |
12m/s |
Security wind speed |
45m/s |
Rated DC voltage |
48V |
Rated speed |
374 r/m |
Rotor diameter |
3200mm |
Protection |
Electromagnetic torque control
and electricity brake |
Type |
3phase permanent magnetism
synchronization generator |
Blade material |
Extra-strong fiber glass |
Packing material |
Plywood box and foam material |
Packing Size |
850*480*350mm |
N. W& G. W(kg) |
117/132kg |
|
|
Wind controller |
Ws2kw/48v wind charger controller
Rated Battery Voltage: 48V
Wind Turbine Maximum Input: 80A
Unload Voltage(factory default): 56V
Unload Current(factory default): 50A |
|
Battery |
12V200AH 4PCS lead-acid battery
Rechargeable battery for wind turbine system,
high storage for wind energy
Free maintenance.
Use life: 5~6years, Warranty: 2years |
|
Off-Grid inverter |
TF2KW/48V pure sine wave wind inverter
110/120/220/230V output; with grid charger build-in
Protection against overload, short circuit, anti-reverse, discharger, etc. |
|
Guy cable tower |
6mtower;
It help fasten wind generator in safe altitude.
Use steel material with rust prevention.
Easy to install |
|
Off grid wind power supply systems-FD3000 |
System
Basic Information |
Wind generator power: 3000W
Annual average energy: 7500kWh
Supply power for air-condition, refrigerator, water pump, washer |
|
Wind generator
|
Model |
FD-3000 |
Rated power |
3000W |
Starting wind speed |
3m /s |
Cut-in wind speed |
3.5m /s |
Rated wind speed |
12m /s |
Security wind speed |
45m /s |
Rated DC voltage |
48V/96V |
Rated speed |
310 r/m |
Rotor diameter |
3700mm |
Protection |
Electromagnetic torque control
and electricity brake |
Type |
3phases permanent magnetism
synchronization generator |
Blade material |
Extra-strong fiber glass |
Packing material |
Plywood box and foam material |
Packing dimension |
870*560* 370mm |
N. W& G. W(kg) |
147/ 170kg |
|
|
Wind controller
|
Ws3kw/48v wind charger controller
Rated Battery Voltage: 48V
Wind Turbine Maximum Input: 125A
Unload Voltage ( factory default ): 56V
Unload Current ( factory default ): 60A |
|
Battery
|
12V200AH 8PCS
Rechargeable battery for wind turbine system,
high storage for wind energy
Free maintenance.
Use life: 5~6years, Warranty: 2years |
|
Off-Grid inverter
|
TF3KW/48V pure sine wave inverter
110/120/220/230V output; with grid charger build-in
Protection against overload, short circuit,
anti-reverse, discharger, etc. |
|
Guy cable tower
|
9m tower;
It help fasten wind generator in safe altitude.
Use steel material with rust prevention.
Easy to install |
|
