Home Generator Products Horizontal Axis Wind Power Generator (XQ-HO5kw)

Horizontal Axis Wind Power Generator (XQ-HO5kw)

Horizontal Axis Wind Power Generator (XQ-HO5kw)
Price: Negotiable
Min Order: 1set
Models: Xq-ho5kw
Power: 5kw
Blade diameter: 6.0m
Rated rotor speed: 220r/min
Rated speed: 10m/s
Rated power: 5kw
Max power: 7kw
Output voltage: 220v
Start up wind speed: 3(m/s)
Work speed: 3-30(m/s)
Security wind: 50(m/s)
Height of tower: 9(m)
Top quality except tower: 285kg
Tower (steel tube): ø 180mm

Output controller system charge controller
Inverter suggested batteries and it's capacity 18PCS 12v200ah
Noise level 50dB
40" container 18sets
System included generator, blade, controller, inverter, battery, anemoscope, vane, tower and accessory
Can loading washing machine, water pump, electric pan, color TV, lighter, fanner, charger
Power 200W 300W 600W 1000W 2000W 3KW 5KW 10KW 20kw 30kw 50kw
Blade diameter (m) 2 2 2.8 3 4 5 6 8 11 12.5 18
Rated Rotated speed(r/m) 400 400 400 400 400 220 220 160 120 100 60
Rated wind  speed (m/s) 8 8 8 8 8 9 9 10 10 10 10
Rated power(w) 200 300 600 1000 2000 3000 5000 10000 20000 30000 50000
Max power(w) 300 450 900 1500 3000 4500 7000 15000 30000 35000 55000
Output voltage(v) 24 24 24 48 96 192 220 380 380 380 380
Start up wind speed(m/s) 3 3 3 3 3 3 3 3 3 3.5 3
Operating wind speed(m/s) 3-25 3-25 3-25 3-25 3-25 3-25 3-25 3-25 3-25 3-25 3-25
Security wind speed(m/s) 40 40 40 40 40 40 40 40 40 40 40
Height of tower (m) 6 6 6 6 6 8 9 12 15 18 18
Weight of top section (kg) 27 30 60 83 95 110 120 600 800 1130 2050
controller Parameter 24V 40A 24V 40A 24V 40A 48V 60A 96V 60A 220v 60A 220v 60A 380v 120A 380v 120A 380v 120A 380v 120A
Inverter Parameter DC24V → user’ s local voltage & frequecy DC24V → user’ s local voltage & frequecy DC24V→ user’ s local voltage & frequecy DC48V→ user’ s local voltage & freque DC96V→ user’ s local voltage & freque DC220V→ user’ s local voltage & freque DC220V→ user’ s local voltage & freque DC380V→ user’ s local voltage & freque DC380V→ user’ s local voltage & freque DC380V→ user’ s local voltage & freque DC380V→ user’ s local voltage & freque
tower pole type(mm) 60*3 60*3 75*4 75*4 89*4 133*5 159*5 219*6 377*6 426*8 free stand tower 18m
20container(sets) 120 96 72 60 48 20 15
40container(sets) 240 192 144 112 96 38 26 10 9 5 4
Capacity and quantity of battery(reference) 12V100AH    2pcs 12V100AH    2pcs 12V150AH    2pcs 12V150AH 4pcs    12V100AH  8pcs 12V100AH    16pcs 12V100AH    18pcs 12V150AH    30pcs 12V200AH    30pcs 12V200AH    60pcs 12V200AH  120pcs
  can supply power for lighting, electric fan, charger tv, lighting, electric fan, charger ice box, washer, waterpump, tv, lighting, electric fan, charger ice box, washer, waterpump, tv, lighting, electric fan, charger ice box, washer, waterpump, tv, lighting, electric fan, charger ice box, washer, waterpump, tv, lighting, electric fan, charger, air condition ice box, washer, waterpump, tv, lighting, electric fan, charger, air condition ice box, washer, waterpump, tv, lighting, electric fan, charger, air condition, samll village ice box, washer, waterpump, tv, lighting, electric fan, charger, air condition, samll village ice box, washer, waterpump, tv, lighting, electric fan, charger, air condition, samll village ice box, washer, waterpump, tv, lighting, electric fan, charger, air condition, samll village
Prod Model: XQ-HO5kw
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Number Of Blade: Three Blade
Stress Way Of Blade: Lift Force
Rotating Shaft: Horizontal
Dezhou Xinqu Energy Technology Co., Ltd. Belongs to Shandong Xinqu Group. It Located Dezhou city, Shandong Province of China, possesses registered capital of RMB6.0 million, fixed assets of RMB80 million, and more than 300 employees, covering an area of 110 acres. Is a Special Manufacture deal with in Wind Turbine, Solar Street Light, garden light, yard light etc Serial Renewable Energy Products., Relying on the Professional transportation Local Land and shipping and professional export operation, the company can provide good and swift service for customers.

Flexible fund operation and good commercial reputation gained for the company not only comprehensive and timely support on document operating and fund using from a number of financial institutions, but also great support from the local government. Besides, flexible foreign exchange settlement system makes the company establish good credit at home and abroad, and brings in continuous commercial advantage and operational efficiency.

Shandong Xinqu Group included: Xinqu International Logistical Company, Xinqu Renewable Energy Technology Company and Hengyang International trading company, main deal with in Renewable energy products as: Wind turbines, Solar Street Light etc Renewable Energy Products. Also agent import and export other products office furniture and hotel furniture, machinery equipment, textile products and so on. Since the company was founded, it has set up huge sales network and formed a good relationship between the company and customers home and abroad, the customers abroad are throughout Europe, Southeast Asia, South Africa, Japan and South Korea and other countries.

In the face of opportunities and challenges of the 21st century, Xinqu people will continue adhering to the business philosophy of "exceed customers" expectations, to achieve common growth", and be together with you to create a better future!
