Oxygen concentration over 90%
Offering stable medical-grade oxygen
Working Theory of Product
1. Molecular sieve: Molecular sieve is the aluminosilicate crystals produced by means of artificial hydrothermal synthesis, which is divided into different models according to its different Si-Al-ratio. Based on the size of the internal cavities inside the crystal, it may accordingly adsorb or exclude different molecules, and decide the sequence of absorption by different molecular polarity and relative polarizable extent of substances, therefore lead to a separation. So it's called "molecular sieves. "
2. The principle of pressure swing absorption: Molecular sieve generates different absorption capacity to different gases, and it has a very strong absorption capacity to certain gas. Meanwhile, the molecular sieve's absorption capacity to the selected gas is related to the environmental pressure, the greater is the environmental pressure, the stronger is its absorption capacity to the selected gas.
Main Technical
Voltage/Frequency: 220V ± 22V, 50Hz ± 1Hz
Power: 350VA
Size: 320*310*605(length× Width× Heighth)mm3
Weight: <16.8 kg
Gas channels: 1
Oxygen Output Pressure: 0.04 ~ 0.06 MPa
Oxygen flow rate: (0 ~ 5) L / min
Oxygen thickness: ≥ 90% under flow rate: (0 ~ 5) L / min
Moisture content: ≤ 0.07G/M3
Carbon dioxide content: ≤ 0.01%
Flow adjustment range: Continuously adjustable under the flow rate: (0 ~ 5) L / min; Tolerance should be ± 10%
Noise: <60dB (A)
Storage conditions: Temperature -40 ° C ~ 55 ° C, humidity ≤ 80%, atmospheric pressure 50 kPa ~ 106kPa
