High Performance Gas Generator for Sale
| Price: |
Negotiable/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Money Gram |
Gas Station of Two Stage Gas Generator
Introduction:This equipment is developed by our company and state professional designing institute. It has absorbed strongpoint from many sides, with advanced design and reasonable structure. The gasifier is equipped with whole water jacket which can produce steam to satisfy its own demand; coal feeder is with reasonable and simple structure, feeding coal and air equally, cleaning dust efficiently and gasifying steadily.
The company is one of the national high-tech enterprises, we have the qualification to manufacture and install pressure vessels. Our qualified products accord with the technology requirement and satisfy the user
The company is one of the member units of the gas info. Net, we have the scientific research institute to do researching, developing and training on coal gasification.
| No. | Name | Unit | Spec. |
| 1 | Inside diameter of gasifier | mm | 3200 |
| 2 | Cross-section area | m 2 | 8.04 |
| 3 | Applicable coal |
| Bituminous coal, jet coal and old lignite |
| 4 | Granularity | mm | 20~40,25~50,30~60 |
| 5 | Gas output | Nm 3 /h | 6000~6500 |
| 6 | Outlet gas pressure | Up-stage | KPa | ≤3.0 |
| Down-stage | KPa | ≤3.5 |
| 7 | Gas outlet temperature | Up-stage | Degree | 80~150 |
| Down-stage | Degree | 450~550 |
| 8 | Gas heating value | Up-stage | KJ/m 3 | 7110~7350 |
| Down-stage | KJ/m 3 | 5225~5434 |
| Mixed | Kcal/Nm 3 | >1450 |
| 9 | Coal consumption | g/m3 Coal gas | <322 |
| 10 | Air consumption | m 3 /kg.c | 2.0~2.5 |
| 11 | Steam pressure | Kpa | 0.26 |
| 12 | Blast pressure | Kpa | 6.5 |
About us:Chaoyang Speed Science & Technology Co., Ltd. ("Speed" for Short) is located by Daling River in Chaoyang City, with convenient traffic conditions and attractive landscape. Speed integrates the products development, technical consultation, equipment manufacture and installation, as well as products sales. Speed has strong technical strength. The main technical staffs are medium and senior engineers holding solid theoretical basis and rich experience in the fields of cement, metallurgical and mining machineries, who have laid the foundation for the development of Speed.Our company has a completed management system and our productions have been selled to 27 provinces all around China. Our company has import&export right ourselves and the productions have been exported to many other countries such as Brazil, Angola, Russia, Vietnam, Mongolia and etc. Our company build a Technology Research Center in 2006 with strong independent researching capacity. Now our company can produce the completed set of cement equipments for 5000t/d class.If you want to get the price, please send us the detailed materials information, such as the hardness of raw materials, feeding size, you required output size, capacity and other special requirement. Our engineer will choose the optimum type and our salesman will send you the reasonable price. Thank you.
| Prod Model: |
3.2m |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Price: |
Negotiation |
| Warranty Period: |
1 Year |
| Installation: |
Under The Guidance |
| Gas Source: |
Gas |
Chaoyang Speed Science & Technology Co., Ltd. ("Speed" for Short) is located by Daling River in Chaoyang City, with convenient traffic conditions and attractive landscape. Speed integrates the products development, technical consultation, equipment manufacture and installation, as well as products sales. Speed has strong technical strength. The main technical staffs are medium and senior engineers holding solid theoretical basis and rich experience in the fields of cement, metallurgical and mining machineries, who have laid the foundation for the development of Speed.
Speed specializes in the business of cement equipments, building materials, as well as metallurgical and mining equipments.
The production base of Chaoyang Speed Science and Technology Co., Ltd is Chaoyang Heavy Machinery Manufacture plant which is located in Chaoyang City, Liaoning Province which is the large-sized key enterprise in National Building Material Machinery Industry. The registered capital of our company is RMB 40 Million. There are total eight subsidiary companys with independent legal person that is Machining Plant, Metallic Structure Company, Large-sized Casting Company, Large-sized Gear Company, Electric Control Company, IMP&EXP Company, Equipment Sales Company. All the subsidiary companys take Chaoyang Heavy Machinery Manufacture plant as core combinated with production design, machining, producing, assembly, supervision and service after sale. Our company is a large-sized comprehensive equipments producing company which mainly produce cement and metallurgy equipments and our company is one of the largest cement equipments producing companys in the East-North of China. The total capital of our company is RMB 0.85 Billion and there are total 1863 employees. The area of our company is 800 acres.
The main equipment of our company is Dia. 8m Vertical Lathe, Dia. 10m gear hobbing machine, 8m Gantry milling machine, 200mm floor-type boring and milling machine, 3200mm blending machine, 150t crane and 40t electric furnace that is controlled by national improved CUP automatically.
The main production of our company is rotary kiln, ball mill, stacker-reclaimer, dryer, grate cooler, vertical mill, roller press, crusher, pre-heater, packing machine, high efficiency separator, electric dust collector, medium-speed coal mill, mixer, nodulizer and etc. The production capacity of our company is 30, 000 tons of equipments and structure parts and 20, 000 tons of casting parts.
Our company has a completed management system and our productions have been selled to 27 provinces all around China. Our company has import&export right ourselves and the productions have been exported to many other countries such as Brazil, Angola, Russia, Vietnam, Mongolia and etc. Our company build a Technology Research Center in 2006 with strong independent researching capacity. Now our company can produce the completed set of cement equipments for 5000t/d class.
