Home Generator Products Good Price 2500kVA Diesel Generator with Yuchai Diesel Engine Made in China

Good Price 2500kVA Diesel Generator with Yuchai Diesel Engine Made in China

Good Price 2500kVA Diesel Generator with Yuchai Diesel Engine Made in China
Price: Negotiable/Set
Trade Terms: FOB
Min Order: 1/Set
Pay Type: L/C,T/T,Paypal,Money Gram,Western Union

Yuchai series engine adopt the power type engine researched by German FEV corporate.
The engine use the whole crankshaft, alloy cast iron engine body and cylinder head.With the small volume, light weight and high reliability, the engine can runs more than 10000 hours.Yuchai engine has advantage of fuel-efficient, four-valve technology, better combustion, small exhaust, low fuel consumption and curve flat.The power covers from 20kw to 500kw.
200KW DIESEL GENERATOR DETAILS
ModelHQ200GFStart MethodDC 24
Generator Prime Power(KW/KVA)200Output Current(A)540
Standby Power(KW/KVA)220Voltage(V)400/230
Power Factor0.8PhaseThree phase, Four Wires
Frequency(Hz)50Weight(kg)2150
Size(mm)LWG
320012001750
Diesel Engine Data
ManufacturerYuchaiModelYC6T500L-D20
Rated Speed(Rpm)1500Diesel Engine Max Power(KW/H)330
Cylinder No.6Arrangement TypeIn-line
Bore×Stroke(mm)129×155Displacement(L)3.61
Intake MethodTurbochargedCompression ratio17.5:1
FuelDiesel FuelFull Load Consumption(g/kw.H)≤209
Oil Capacity(L)14Start MethodElectrical
Engine Cooled MethodRadiator Max 40ºC, fans are driven by belt with safety guard.
Alternator Data
ManufacturerChina StanfordModelXN300
Rated Power(KW/KVA)200/220Excitation TypeBrushless
Insulation ClassHProtection GradeIP22
Unload Voltage Adjustment≥±5%Stable Voltage Adjustment±1%
Efficiency (%)94.8Voltage Control MethodAVR

Standard Configuration of Yuchai engine generators:

1.Yuchai diesel engine.

2.Alternator:100% pure copper wires, rotation magnet, different brands according to your request.

3.Standard control panel, LCD panel or mechanical panel.

4.Water tank, with protection guard.

5.Shock absorber system:Protect the generator during its working period.

6.Maintenance-free start battery.

7.Battery connecting cables

8.Maintenance manuals of engine, alternator and generator.

9.Maintenance tools.

10.Standard steel underframe with stoving varnish.

11.Standard export plywood package.

12.Spare parts for maintenance (as your require)

Yuchai series generator working conditions:

1.Yuchai generator can be used continuously every day, and with electronic governor make little change of rotate speed and stable operation.

2.Application area:Widely used for shop, hospital, high-way, station, construction, farm, etc.

3.Maintenance:The overhaul period is over 10000 hours;And it will reduce the fault rate and extend the lifetime of the unit.

4.Above suggestions are based on our experience and are intended only as reference.
1.Who we are?

Weifang Huaquan Power Machinery Co., Ltd, located in weifang city, Shandong Province, China.We are specialized in producing generators for more than 10 years.We have our own registered trademark, production line, testing equipment, sales team and R&D team.

2.Our main products.

We dedicate to produce diesel generators, gas generators, water pump units and diesel engines with pulley etc.

Our main engine generator brands:Cummins, Isuzu, Deutz, Steyr, Weichai, Weifang (Ricardo), Yuchai, Yandong, Jichai, Changchai etc.

Our main generator types:Land-based open frame generator, silent generator, Automatic generator, and Trailer generator etc;

Marine generator:Variety models for marine diesel generators.

3.Our promise and after- sale service

Huaquan Power focus on quality and responsibility.We pays more attention to the quality what we offer to our client and also care the after sale service for our customers.

(1).Huaquan Power series diesel generators offer one year warranty or 1000 running hours, during its warranty time, we offer spare parts for free.(Caused by the quality problems)

(2).When you buy our generator, we suggest you choose our spare parts service pack.
When you need buy spare parts, you can get them from us all the time.

(3).When you meet problems, you will easy to contact with us.

4.Delivery and Payment terms:

(1) Delivery always after your payment within 2-7 days, we have so many sets in stock, any time you can order from us.

(2)We accept T/T, L/C payment, 30% as deposit.




Prod Model: HQY200GF
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Power(Kw/kVA): 200
Output Current(a): 360
Voltage(V): 400/230
Rated Speed(Rpm): 1500/1800
Cylinder No.: 6
Excitation Type: Brushless
Intake Method: Turboharged
Phase: Three Phase, Four Wires
Color: as Your Requirement
Cooling System: Water Cooled
Type: Basic Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Output Type: AC Three Phase
Huaquan Power is specialized in producing diesel generator set, diesel generator, generator set, diesel generating set, generating, generating set, generator diesel, power generator, gas generator, nautral gas generator, eletric generator, alternator, diesel engine etc. We have open frame generator, automatic generator, trailer generator, silent/soundproof diesel generator, water pump etc. And the brands include Cummins, Perkins, Deutz, Steyr, Isuzu, Ricardo, Yuchai, as well as famous brands of alternator, such as Stamford, Faraday, Leroy-somer, Qiji. Power ranges from 3kw to 1000kw

Huaquan Power Mchinery Co., Ltd, located in diesel engine manufacturing powerhouse-Weifang, the capital of kites.

Huaquan Power has more than 500 employees worldwide and it has four advanced production lines, sophisticated testing equipment, complete quality management system, and marketing all around the world in the past 10 years, such as Southeast Asia, the Middle East, Africa and other regions.

Huaquan Power ensures that providing the energy saving, environment protection, high quality and reliable diesel engine and generators, to ensure user satisfaction and rest assured! We sincerely look forward to your cooperation!
