GENERATOR Model KDE6500T
FrequencyHz 50 60
Rated output: kVA 5.5 6.3
Max. Output: kVA 6 7
Rated. AC voltage: V 230/400 240/416
Current: A 7.9 8.7
Phase 3-Phase
DC output: 12V/8.3A
Power factorCOS COS=0.8
Alternator type selfexcited, 2pole, 3-phase alternator
Starting system Electric Starter
Operatong noise lecelat 7mdB(A) 72
Fuel tank capacityL 15
ENGINE Model KM186FA (EPA model)
Type Single-cylinder, vertical, 4-stroke air-cooled diesel engine
Bore * Stroke(mm) 86*72
Fuel Summer: 0# Winter: -10#
Lubricatiom oil Model: SAE10W-30(above CD grade
Lubricatiom oil volumeL 1.65
Fuel comsumption Rateg. Kw/h) 275.1 281.5
DisplacementL 0.418
Power/speed: KW, r/min 5.7/3000 6.3/3600
Compression Ratio 19
Combustion system Direct lnjection
STANDARD FEATURES Voltmeter Yes
AC Output Socket 2
AC circuit breaker Yes
Oil warning light Yes
Oil alert Yes
OPTIONAL FEATURES DC circuit breaker Optional
Calculagraph Optional
Big Wheel Optional
Current meter Optional
ATS Optional
AMF Digital Panel Optional
Remote control Optional
DIMENSIONS Structure: Soundproof
Dimensionmm 970*558*768
Dry weightkg 144.5
20FT: 72SETS
We reserve the right to change specifications without notice.
Seemark locates in kunshan city with Shanghai neighboring in east, which is one of the most developed areas of the world manufacturer in high technology.
Since its establishment in DEC. 1995, seemark developing in diesel generator set &gasoline generator set with fastest speed for growing and developing at world market, covering an area about 43, 000 square meters plant of European style, owns 7 sets of auto-assembly producing lines, 2 sets of auto-cycle testing lines and first-class in world of detecting equipments, has 386 expert staffs now, 18 professional R&D engineers including 3 senior engineers.
With powerful R&D, good management& strict quality control, and professional technicians, the company has the ability to produce more than 500, 000 engines, generators and water pumps all together.
History:
In DEC. 1995, founded in kunshan, China
In 2004, acquired quality management certification of ISO9001: 2000 and international network certification in manufacture/assembly of small synchronization gasoline& diesel generator.
In June 2006, honoured to be one of the China ten publish accepted famous brands in generator sets. During this time, we have past the CE, EPA certification for products exporting requirement.
In December 2006, honoured the certification of the first class enterprise producing export industrial products in jiangsu province.
In 2011, move to yingbin road, the new and big factory
We Supply
Cummins engine generaor 20-1500kVA
SDEC 68-735kVA
Volvo Penta 85-625kVA
YTO 60-130kVA
FAW 15-375kVA
WUDONG 100-825kVA
MTU 650-3000kVA
MITSUBISHI 4.2-2000kVA
JOHN DEERE 31-410kVA
MAN 350-1000kVA
Alternator: Stamford, Leroy somer
etc
