Specifications: Diesel generator set, diesel generator, generator, silent generator, soundproof / weatherproof canopy, genset
1). Generator control monitor with LED display, model GCM338; Directly meter display, model GTR168; Optional with Deepsea brand control panel;
2). Generator protection provided for short, over-current, over-speed, high water temperature and low oil pressure;
3). Generator standard parts: Industrial type muffler, exhaust pipes, flexible exhaust bellows, vibration-damping rubber, lead-acid batteries, connective cables, user manual, spring isolator, technical papers
4). Generator with Small volume, light weight, low noise, low fuel consumption, water-cooling with water tank and fan
5). Generator type option with Soundproof / weatherproof canopy
Engine: Cummins
A) Engine model: 6BT5.9-G2;
B) Multi-cylinder in-line engine, 4-stroke, direct injection
C) Electronic governors
D) PT fuel injection pump
E) Electric motor starting system
F) Low discharge, and low fuel consumption
G) Installed conveniently and maintained easily
Alternator: Marathon
Alternator model: MP-80-4
Option with: Stamford, Lorysomer, Engga, Kaijieli
A) Brushless, self-excited, 4-pole, single bearing
B) AVR self-regulated, voltage regulation rate ≤ ± 1%
C) IP21 protection grade
D) Class H insulation
E) Radio interference restraining accords with stipulation of VDE0875-N and ISO8528
F) Moistureproof, sand-proof, dustproof, salt-proof and vibration-proof
Generator Parameters:
1) Model of connection: 3-phase-4-line
2) Rated power factor: 0.8 (lagging)
3) Wave distortion: Below 10%
4) Power supply voltage: 24V
5) Volt fluctuation: Below 0.5%
6) Voltage / frequency fluctuation: ≤ 0.5%
