BRIEF INTRODUCTION
1\3-15Kw series of ordinary diesel generator sets have been provided with high quality water-cooled (condensor) diesel engine, those engine can work well in every kind of condition.
2\The structurce of generating sets, the engine has been coupled with alternator through v-belt or coupled directly with alternator, both of them have been installed on the basis of anti-shock pad, the general -sets has been fixed on the frame of steel pipes which has for wheels.
3\Other features: Easy to operate and maintain; Control panel capacitor type voltage regulator; No-fuse circuit breaker; Over-current protection; Wheels type;
OTHER MAIN PERFORMANCE:
1. Voltage stead-state regulation-1--1% fluctuation ratio 1.5% transient
-state regulation-15~20% stead time 5s Frequency stead-state
Regulation 5% fluctuation ratio 1.5% Transient-regulation -1--1%stead
Time5s
2. The noise of gen-sets should be no more than 85db(a)the fuel
Consumption is no more than 2.5kg/kw. H.
Sets Model
| GF1-3KW
| GF1-5KW
| GF1-8KW
| GF1-10KW
| GF1-12KW
|
E
N
G
I
N
E
| Model
| S175
| S195
| S1100
| S1105
| S1100
|
Type
| Horizontal, single-cylinder, four-stroke, water-cooled
|
Rated speed(r/min)
| 1500/1800
|
Fuel Consumption
| 270
| 250
| 250
| 250
| 250
|
Cooling type
| Closed circulating cooling(condensor)
|
Mode
| STC-3(ST-3)
| STC-5(ST-5)
| STC-8(ST-8)
| STC-10(ST-10)
| STC-12(ST-12)
|
A
L
T
E
R
N
A
T
O
R
| Rated output(KW)
| 3
| 5
| 8
| 10
| 12
|
Rated Current(A)
| 5.4(13/25)
| 9(21.7/43.5)
| 14.4(32.6/65.2)
| 18(43.5/87)
| 21.6(52.2/104.3)
|
Rated Voltage(V)
| 400V/230V
|
Frequency(hz)
| 50HZ/60
|
Power factor(cos@)
| 0.8/1.0 lagging
|
Type
| Triple harmonic, 3-phase(single-phase)
|
Net Weight(kg)
| 170
| 320
| 350
| 360
| 380
|
Packing size LWH(mm)
| 1050*500*720
| 1320*650*860
| 1320*650*860
| 1320*650*860
| 1320*650*860
|
Fujian Rtou Power Machinery Co., Ltd., one of the biggest enterprises, lies in "China Electrical Machinery and Appliances City_Fuan". Rtou is a privately enterprise established in 2008, which is a comprehensive electrical machinery manufacturing company integrating product designs, production, marketing and service.
Rely on scientific and technological development, we continue to provide users high-tech products, which is our consistent pursuit. On the basis of absorbing the foreign advanced technology, we have already fetch in 12 lines advanced international motor production, . The main products manufactured by our company consist of more than 10 series, over 100 types, involving generators, diesel generating sets, gasoline generating sets and concrete cutter, of which all of our products have passed the national attestatiion CCC, CE certificate, Nigeria Soncap and EPA certificate.
Rtou is a young enterprise, but she owns the fresh and great-hearted blood, which make her more charmful. "Quality assurance, customer first" is the agreement of Rtou executives. Communicate with the domestic industry, scientific research institutions exchange and cooperation so as to improving the quality, such as: Design and production, commissioning and maintenance. Then occupy the market, and expand the scale of the company. We have been moving forward to a more prosperous achievement under the fierce competition.
Today, Rtou staff pursue the guidelines--"aggressive, realistic, strict and unity" to blaze new trails. We make technology as the core, quality as life and users to God, dedicated to provide you with the highest & cost-effective products and meticulous after-sales service inorder to shape a bright future.
