Rated frequency Hz 50 60
Rated output power (KVA) 12 13
Max. Power (KW) 13 14
Rated voltage V 115/230 120/240
Phase No. Single
Power factor (cosφ ) 0.8
Insulation F
Pole No. 2
Exciting way Brush, exciting-self voltage-constant (with AVR)
Panel type Intelligent
Output socket Single-phase socket\wiring terminal
DC12V output 12V, 8.3A
Noise (7m)dB(A) 75
Structure type half-closed
Engine model LP2V86
Type V-twin, two-cylinder, four-stroke, DI
Cylinder No. -bore × Stroke (mm) 2-86*72
Total displacement ml 836
Rated power kW/ rated speed r/min 12/3000 13/3600
Compressed ratio 20: 1
Cooling way Air-cooled
Lubricating way Pressure & splashing
Starting way Electric
Fuel used 0#(summer)-10#(winter)-35#(cold winter)light diesel
Oil used SAE10W30
(CD grade above)
Lubricating oil capacity (L) 1.7
Starting motor capacity (V-kW) 12V 1.4kW
Dynamo capacity (V-A) 12V 8.3A
Battery capacity (V-Ah) 12V 45AH
Fuel consumption (g/kW. H) ≤ 270 ≤ 290
Fuel tank capacity of the generator( L) 25
Continuous operation time of the generator(H) 8.5 8
