This machine is suitable for mine, bank, factory, shop, firm, residence community, theatre, hospital, post office., etc.
We have a strict quality guarantee system and possessed rigid criteria to carry out the quality management standard. We are one of the first enterprises to be legalized by ISO9001: 2000, and obtains ISO/TSI 16949. Now the R series products are approved by CE, European Emission and EPA.
Attention:
The price is of basic configuration, not including the cost of oil, battery, fuel tank.
|
Generator |
Frequency(Hz) |
50/60 |
|
|
max.output(kw) |
4.6/5.0 |
|
|
Rated output(kw) |
4.2/4.6 |
|
|
Rated AC voltage(V) |
120,220,230,120/240,220/380 |
|
|
Power factor(cosΦ) |
cosΦ=1 |
|
|
DC output(V) |
12V/8.3A |
|
|
Phase |
single phase |
|
|
alternator type |
Self-excited,2-pole,single phase alternator,, |
|
|
Starting system |
Electric or Electric |
|
|
Noiselevel(at 7m)7 |
80-85 |
|
|
fuel tank capacity(L) |
12.5 |
|
|
Continuous work(hr) |
7.1/6.5 |
|
Engine |
Model |
HR186F |
|
|
Engine type |
single-cylinder,vertical,4-stroke,air-cooled diesel engine,,, |
|
|
Bore X StrokeX(mm) |
86x70 |
|
|
Fuel |
0# or-10#light diesel oil 0#-10# |
|
|
lubrication oil volume(L) |
1.65 |
|
|
Combustion system |
Direct injection |
|
Standard features |
Voltmeter |
yes |
|
|
AC Output Socket |
2 |
|
|
AC circuit breaker |
yes |
|
|
Oil warning light |
yes |
|
|
Oil alert |
yes |
|
Optional features |
DC circuit breaker |
Optional |
|
|
Calculagraph |
Optional |
|
|
Big wheel |
Optional |
|
|
Three phase Voltage |
Optional |
|
|
ATS |
Optional |
|
Dimensions |
dimension(L*W*H)(mm) |
700x470x600 |
|
|
Net weight(kg) |
84 |
