Rated voltage(V): 110, 120, 220, 230, 240, 220/110, 240/120
Rated current(A): 22.7
Highest power(KW): 5.2
Generator Mode: Brush, Single phase
Rated power(KW): 5
Rated frequency(Hz): 50/60
Voltage adjust style: Auto-adjust
DC output: 12V-8.3A
TYPE: 188FD
Displacement(ml): 389
Max. Output (HP): 13
Engine speed (r/pm): 3000/3600
Start system: Electric start
Fuel tank capacity (L): 25
Continues work (h): 9
Noise level (at 7m): 68db
Dimensions (mm): 670*510*545
Package dimensions (mm): 710*530*620
G. W(Kg): 90
20/40FT/40HQ(set): 105/210/280
Founded in 2000, Chongqing Aoyuan Power Machinery Manufacture Co., Ltd is a professional manufacturer and exporter of Gasoline engines, Motorcycles, Pumps, Generators and Garden machines. Located in Chongqing city(which is the biggest port of the southwest China mainland), we have convenient access to both suppliers of raw materials and seaports for shipping orders, so we could manufacture products with high price performance ratio.
Our production facilities cover a floor area of 3, 300 square meters. We employ over 300 workers including 28 senior engineers and skilled technicians. Our annual output capacity now totals 300, 000 motorcycles. All of the production processes are conducted under rigid quality control measures, which have thereby earned us the ISO 9001 certification. Based on high technology, super quality and a good after-sales services system, Aoyuan has already become a good choice for many customers in most countries in Southeast Asia, the Middle East and part of Africa. It is our sincere hope that we shall provide you with the best products and service as you expect.
Guaranteed with quality and first-class service, we would be honored to add you to our list of esteemed customers worldwide. If you have any questions or would like to discuss a custom order, please feel free to contact us directly for further information.
