Rated frequency(Hz)
50 60
Rated voltage(V)
400/230 240/230
Rated current(A)
9 9.9
Rated output power(kW)
5.0 5.5
Rated rotation speed(rpm)
3000 3600
Power factor(cos)
0.8(Appliced to kVA)
Phase number
Three phase
Overall dimension(L*W*H)[mm(in)]
680*510*540
Engine model
KG390
Engine type
Single cylinder, 4-stroke, air-cooled OHV, gasoline engine
Rate power[kW(HP)/rpm]
7.7(10.47)/3600
Bore*stroke[mm(in)]
88*64(3.46*2.52)
Compression ratio
8.5: 1
Total displacement[L(cu. In)]
389(23.74)
Fuel consumption at full load[g(ml)/kW. H]
< 395(534)
Fuel
90#automotive unleaded gasoline
Cooling system
Forced air-cooled
Lube Capacity
1.1(0.26)
Lube
SAE10W30(above CC grade)
Low oil pressure alert system
With
Spark plug
F6RTC
Noise level[dB(A)@7m]
70~74
Inition system
T. C. I
DC output
12V 8.3A
Rotation direction (view from flywheel)
Clockwise
Fuel capacity[L(gal. )]
25(5.5)
Rated frequency(Hz) |
50 |
60 |
Rated voltage(V) |
400/230 |
400/230 |
Rated current(A) |
9 |
9.9 |
Rated output power(kW) |
5.0 |
5.5 |
Rated rotation speed(rpm) |
3000 |
3600 |
Power factor(cos) |
0.8(Lag) |
Phase number |
Three phase |
Overall dimension(L*W*H)[mm(in)] |
855× 510× 540(33.66× 20.08× 21.26) |
Dry weight[kg(ibs. )] |
90(198) |
Structure mode |
Open-frame type |
Engine model |
KG390 |
Engine type |
Single cylinder, 4-stroke, air-cooled OHV, gasoline engine |
Rate power[kW(hp)/rpm] |
7.7(10.47)/3600 |
Bore*stroke[mm(in)] |
88× 64(3.46× 2.52) |
Compression ratio |
8.5: 1 |
Total displacement[L(cu. in)] |
389(23.74) |
Fuel consumption at full load[g |
< 395(534) |
Starting system |
X3: Recoil Starter E3: electric starter |
Fuel |
90#automotive unleaded gasoline |
Cooling system |
Forced air-cooled |
Lube Capacity |
1.1(0.26) |
lube |
SAE10W30(above CC grade) |
Low oil pressure alert system |
With |
Spark plug |
F6RTC |
Noise level[dB(A)@7m] |
70~74 |
Inition system |
T. C. I |
DC output |
12V 8.3A |
Rotation direction (view from flywheel) |
Clockwise |
Fuel capacity[L(gal. )] |
25(5.5) |
WUXI WORLDBEST KAMA POWER Co., Ltd. is a share-controlled subsidiary company of KAMA Co., Ltd., under the leadership of China KAMA GROUP.
KAMA Co., Ltd. (Share Code. 900953) is a domestic super manufacturing Group, producing Automobile, Auto parts and components, Multifunctional middle and small diesel engines, Marine and Land-use Generator set, Tractors, electro-mechanical products and general-purpose machinery. The company now has the total capital assets 3.1billion RMB Yuan and annual sale revenue reaching 5 billion RMB Yuan.
Located besides 'Tai Lake' shore, with pretty scenery, WUXI WORLDBEST KAMA POWER Co., Ltd. Started a registered capital of 35million RMB Yuan, with Enterprise area about 70, 000sq. M and floor space about 50, 000sq. M. At present, the company has about 800 staff, including 80% of secondary education personnel or above, and 20% of senior engineers and technicians.
WUXI WORLDBEST KAMA POWER Co., Ltd., as subsidiary company of KAMA GROUP, professionally manufacture mini-type air-cooled diesel generator, generator set, gasoline generator set, water pump set and tiller managers under 'KAMA' brand. With making good use of the powerful and high-effective matching system around, the company achieves the year productivity of 300, 000units.
Having been cooperated with many domestic Scientific Research Institutions, the company has the strong capability on researching and developing new products which renovated continually. Until now, we have obtained a high honor among the same industry and customers.
WUXI WORLDBEST KAMA POWER Co., Ltd. is an extraversive, researching and manufacturing cooperation, and exports to more than 100 countries and areas all over the world. Meanwhile, we have set up a domestic tridimensional marketing mode based on the provincial Agency and trade Agency.
