1 Low fuel consumption, low noise, low pollution, high efficiency and environmental protection.
2. Our products has the strict test system, the voltage and frequency is stability
3. FOB price, high quality and good service.
4. Diverse styles and humanized choice, and can be widely used in the family supermarkets hotels, pleases such as the temporary outage.
Rated frequency(Hz) |
|
50 60 |
Rated voltage(V) |
|
230 230/115 |
Rated current(A) |
|
7.4 8.3/16.5 |
Rated output power(kW) |
|
1.7 1.9 |
Rated rotation speed(rpm) |
|
3000 3600 |
Power factor(cos) |
|
1.0 |
Phase number |
|
Single phase |
Overall dimension(L*W*H)[mm(in)] |
|
590x430x430(23.23x16.93x16.93) |
Dry weight[kg(ibs. )] |
|
39(85.8) |
Structure mode |
|
Open-frame type |
Engine model |
|
KG160 |
Engine type |
|
Single cylinder, 4-stroke, air-cooled OHV |
Rate power[kW(hp)/rpm] |
|
3.3(4.49)/3600 |
Bore*stroke[mm(in)] |
|
68× 45(2.68× 1.78) |
Compression ratio |
|
8.5: 1 |
Total displacement[L(cu. in)] |
|
163(9.95) |
Fuel consumption at full load[g(ml)/kW. h] |
|
< 395(534) |
Starting system |
|
Recoil Starter |
Fuel |
|
90#automotive unleaded gasoline |
Cooling system |
|
Forced air-cooled |
Lube Capacity |
|
0.6(0.14) |
lube |
|
SAE10W30(above CC grade) |
Low oil pressure alert system |
|
With |
Spark plug |
|
F6RTC |
Noise level[dB(A)@7m] |
|
70~74 |
Inition system |
|
T. C. I |
DC output |
|
12V 8.3A |
Rotation direction (view from flywheel) |
|
Clockwise |
WUXI WORLDBEST KAMA POWER Co., Ltd. is a share-controlled subsidiary company of KAMA Co., Ltd., under the leadership of China KAMA GROUP.
KAMA Co., Ltd. (Share Code. 900953) is a domestic super manufacturing Group, producing Automobile, Auto parts and components, Multifunctional middle and small diesel engines, Marine and Land-use Generator set, Tractors, electro-mechanical products and general-purpose machinery. The company now has the total capital assets 3.1billion RMB Yuan and annual sale revenue reaching 5 billion RMB Yuan.
Located besides 'Tai Lake' shore, with pretty scenery, WUXI WORLDBEST KAMA POWER Co., Ltd. Started a registered capital of 35million RMB Yuan, with Enterprise area about 70, 000sq. M and floor space about 50, 000sq. M. At present, the company has about 800 staff, including 80% of secondary education personnel or above, and 20% of senior engineers and technicians.
WUXI WORLDBEST KAMA POWER Co., Ltd., as subsidiary company of KAMA GROUP, professionally manufacture mini-type air-cooled diesel generator, generator set, gasoline generator set, water pump set and tiller managers under 'KAMA' brand. With making good use of the powerful and high-effective matching system around, the company achieves the year productivity of 300, 000units.
Having been cooperated with many domestic Scientific Research Institutions, the company has the strong capability on researching and developing new products which renovated continually. Until now, we have obtained a high honor among the same industry and customers.
WUXI WORLDBEST KAMA POWER Co., Ltd. is an extraversive, researching and manufacturing cooperation, and exports to more than 100 countries and areas all over the world. Meanwhile, we have set up a domestic tridimensional marketing mode based on the provincial Agency and trade Agency.
