Cotile is in the line of Diesel generators, Diesel generator set, Gasoline generators, Water pump, Pressure washers from 2006.
Our factory has passed ISO9001, CE, EPA, GS, Standard of Europe letting certificate.
More than 95% of the products were exported to America, Middle-east, Southeast asia, European union, South
America and Africa, etc.
Cotile promise to provide customers with high quality product at best competitive price.
Cotile takes the overseas markets as the most important part for development.
Cotile, your best partner for mutual benefits.
|
Engine |
Model |
GG1200 |
GG1500 |
|
Model |
154F |
154F |
|
Type |
Forced air-cooled 4-stroke OHV single cyliner |
|
Displacement(ml) |
86 |
86 |
|
Max output(hp/rpm) |
2.4/3600 |
2.4/3600 |
|
Ignition System |
Non-contact Transistorized Magneto |
|
Starting System |
Recoil and manual-operated |
|
Fuel Tank Capacity(I) |
5.5 |
5.5 |
|
Fuel Consumption(l/h) |
0.8 |
0.8 |
|
Continuous Operating Hours(h) |
6.5 |
6.5 |
|
Engine Oil Capacity |
0.4 |
0.4 |
|
Operating Noise at 7m(db) |
60 |
60 |
|
Generator |
Phase Number |
Single phase |
Single phase |
|
Rated Frequency(hz) |
50/60 |
50/60 |
|
Rated Voltage(v) |
220/110 |
220/110 |
|
Power Factor |
1 |
1 |
|
Rated Output(kw) |
0.8 |
1 |
|
Max AC Output(kw) |
1 |
1.1 |
|
DC Output in Low Voltage |
12V,8.3A |
12V,8.3A |
|
Packing |
Dimension LxWxH(mm) |
470x380x390 |
470x380x390 |
|
Carton |
Brown Carton |
Brown Carton |
|
N.W./G.W(kg) |
20/22 |
24/26 |
Cotile is in the line of Generator Set, Diesel generators, Diesel generator set, Gasoline generators, Water pump, Pressure washers from 2006.
Our factory has passed ISO9001, CE, EPA, GS, Standard of Europe letting certificate.
More than 95% of the products were exported to America, Middle-east, Southeast Asia, European Union, South America and Africa, etc.
Cotile promise to provide customers with high quality product at best competitive price.
Cotile takes the overseas markets as the most important part for development.
Cotile, your best partner for mutual benefits.
